Fronius GEN24 User Manual

power and by "Cos φ Minimum". For the characteristic curves, the data points
must be entered in the X‑axis (effective power) and in the Y‑axis (Cos φ).
Point Parameter Range of val-
ues
Description
1 "Active Power
(% of Nominal
Apparent
Power)"
0 % ‑ 100 % Effective power in percent
[%] related to the nominal ap-
parent power S
n
.
"cos φ - Power
Factor"
0 ‑ 1 Set value of Cos φ.
"Direction / Ex-
citation"
The current direction corres-
ponds to the generator
counter arrow system.
Under-Excited Under-excited operation = in-
ductive operation = reactive
power is drawn = reactive cur-
rent is fed in ahead of the
active current.
Over-Excited Over-excited operation = ca-
pacitive operation = reactive
power is supplied = reactive
current is fed in lagging the
active current.
2 "Active Power
(% of Nominal
Apparent
Power)"
0 % ‑ 100 % Effective power in percent
[%] related to the nominal ap-
parent power S
N
.
"cos φ - Power
Factor"
0 ‑ 1 Set value of Cos φ.
"Direction / Ex-
citation"
The current direction corres-
ponds to the generator
counter arrow system.
Under-Excited Under-excited operation = in-
ductive operation = reactive
power is drawn = reactive cur-
rent is fed in ahead of the
active current.
Over-Excited Over-excited operation = ca-
pacitive operation = reactive
power is supplied = reactive
current is fed in lagging the
active current.
64

Fronius GEN24 Specifications

General

Type	Hybrid Inverter
Power Range	3.0 kW to 10.0 kW
Max. DC input voltage	1000 V
Number of MPP Trackers	2
Operating Temperature Range	-25°C to +60°C
Efficiency	98.2%
MPPT voltage range	200 - 800 V
Interfaces	Wi-Fi / Ethernet / USB / RS485
Warranty	5 years (extendable)
Cooling	Active cooling
