156
Fronius IG Plus
120 V
Input data
Output data
General data
Safety equipment
MPP voltage range 230 - 500 V DC
Max. input voltage
(at 1000 W/m² / -10 °C in an open circuit)
600 V DC
Max. input current 46.2 A DC
Nominal output power (P
nom
)10 kW
Max output power 10 kW
Nominal AC output voltage 3 ~ NPE 400 / 230 V
Grid voltage tolerance +10 / -15 %
1)
Nominal output current (three-phase) 14.5 A AC
Nominal frequency 50 - 60 Hz
1)
Harmonic distortion < 3,0 %
Power factor (cos phi) 1
0.85 - 1 ind./cap.
3)
Max. permitted grid impedance Zmax at PCC
2)
None
Maximum efficiency 95,9 %
Euro. efficiency 95,4 %
Night consumption 1.72 W
Cooling Controlled forced-air ventila-
tion
Degree of protection IP 54
in Australia, IP 44
Dimensions h x w x d 1263 x 434 x 250 mm
Weight 49.2 kg
Permissible ambient temperature
(with 95% rel. humidity)
- 20 °C - +55 ?
EMC emissions class B
Over-voltage category (OVC) AC 3 / DC 2
DC insulation measurement Warning / Shutdown
4)
at R
ISO
< 500 kilohms
DC over-voltage protection integrated
Protection against reverse polarity integrated
Manifestation of DC overload Operating point shift
