53
EN
Fronius Primo
dummy
Explanation of
footnotes
1) The values quoted are default values; the inverter is configured specifically to meet
the needs of the country in question.
2) Depending on the country setup or device-specific settings
(ind. = inductive; cap. = capacitive)
3) PCC = interface to the public grid
4) Maximum current from the inverter to the solar module when an error occurs in the
inverter or when the insulation between the AC and DC side is defective
5) Guaranteed by the electrical configuration of the inverter
6) Current peak when switching on the inverter
7) Depending on the country setup
Applicable stand-
ards and guide-
lines
CE mark
The devices comply with all the requisite and relevant standards and guidelines that form
part of the relevant EU Directive, and are therefore permitted to display the CE mark.
Circuit to prevent stand-alone operation
The inverter has an approved circuit to prevent stand-alone operation.
Grid failure
The standard measurement and safety procedures integrated into the inverter ensure that
in the event of a grid failure, the feed-in of energy is immediately interrupted (e.g. switch-
off by the energy supplier or damage to lines).
Nominal grid voltage 1 ~ NPE 230 V
Mains voltage tolerance +10 / -5 %
1)
Nominal frequency 50 - 60 Hz
1)
Protection class IP 65
Dimensions h x w x d 645 x 431 x 204 mm
Weight 16.75 kg
