Function tests
Function Functions that the testing personnel consider to be relevant must be tested for correct op-
eration.
Energising and feeding-in of the inverter.
Grid on/off devic-
es
Evidence of proper operation must be provided by measurement or visual inspection.
AC and DC main switch check (perform when under no or minimal load, but not in standby
mode)
- Switch off DC main switch -> inverter must switch to error and stop feeding in energy
- Switch off AC main switch -> inverter switches off and display goes out
- Switch on AC main switch and DC main switch
- Perform a fan test - see operating instructions
Indicators and
control elements
- Check display for correct function
- Check that controls work in line with the operating instructions

Fronius Primo 8.2-1 Specifications

General

AC Nominal Output Power	8200 W
Frequency	50 / 60 Hz
Dimensions (Height x Width x Depth)	645 x 431 x 204 mm
Protection Class	IP65
Max. Apparent AC Power	8.2 kVA
THD	< 3%
DC Input Voltage Range	200 - 800 V
Number of MPP Trackers	2
DC Connection	MC4
Nominal AC Voltage	230 V
AC Connection	Screw terminal
Operating Temperature Range	-25°C - +60°C
