(4) Symbol with number
Error issued, with code for the corresponding status code. Detailed in-
formation can be found in the "Status codes" section.
(5) Button symbol with check mark
Charge was correctly ended with the "Pause/Start" button.
(6) Button symbol with cross
Charge was ended without pressing the "Pause/Start" button.
(7) Charge details
Display of certain battery data at the beginning and at the end of the
charge:
Number of cells
Ah
Curve
Type of battery
Configuration
mode
Configuration mode offers the following setting options:
Charging settings: Settings for the battery
-
Battery type, e.g., "Wet".
-
Charging characteristic, e.g., "IU".
-
Capacity (Ah) or charging time (h), depending on the charging characteristic.
-
Cells: Voltage (V) and number of battery cells or automatic setting of the
number of cells.
CAUTION!
Risk of damage to the battery.
Damage to the battery may result.
▶
Only use the automatic setting of the number of cells for batteries with
the following nominal voltage values: 12 V and 24 V for 24 V devices, 24
V and 48 V for 48 V devices.
▶
Do not use the automatic setting of the number of cells on deeply dis-
charged batteries.
-
Further settings:
For individual adjustment of the charging characteristic.
Additional functions: Zusatzfunktionen
-
Blue LED
-
External start/stop
-
Refill indicator
-
Option Section
-
At mains failure restart charging
34
