Fronius Symo 6.0-3-M Service Manual & Spare Parts List

108
Replacing other
components
WARNING!
Follow the safety rules (see start of "Safety" chapter)
If the following components are faulty, the complete inverter must be replaced:
- Housing parts (except lid)
- Inductors
- Heat sink
- Seals (except the seal on the lids)
The lids (DATCOM lid and power module lid) can be replaced as an assembly with sprayed
seal.

Fronius Symo 6.0-3-M Specifications

General

AC Nominal Output	6.0 kW
Max. Input Voltage	1000 V
MPP Voltage Range	200 - 800 V
Number of MPP Trackers	2
Protection Rating	IP66
Efficiency	98.1%
Max. Apparent AC Power	6.0 kVA
Frequency	50 / 60 Hz
THD	< 3%
Protection Class	I
DC Connection	MC4
Operating Temperature Range	-25°C to +60°C
DC Input Voltage Range	200-1000 V
AC Connection	Screw terminals
Cooling	Forced air cooling
