Fronius Symo Advanced 10.0-3 208-240

60
Technical Data
Fronius Symo Advanced 10.0-3 208-240 12.0-3 208-240
Input Data
MPP voltage range 300 - 500 V DC
Input voltage range (at 1,000 W/m²/14°F in an open circuit) 200 - 600 V DC
Max. input current (MPP1/MPP2)
(MPP1 + MPP2)
25.0/16.5 A
41.5 A
Max. short circuit current of solar modules (I
SC PV
) (MPP1/MPP2) 37.5/24.8 A
Max. backfeed current from AC grid
1)
0.0 A
2)
Output Data
Nominal output power (P
nom
) 9,995 W 11,995 W
Max. output power (+104°F) 9,995 W 11,995 W
Max. output power (+140°F)
at 208 V 8,000 W 8,000 W
at 220 V 8,600 W 8,600 W
at 240 V 8,600 W 8,600 W
Phases 3 ~ NPE
Nominal grid voltage
at 208 V 120/208 V
at 220 V 127/220 V
at 240 V 120/240 V
Operating range AC voltage -12 ... +10%
Adjustment range for grid voltage 60 - 152 V/104 - 288 V
Max. continuous output current at V
nom
at 208 V 27.7 A 33.3 A
at 220 V 26.2 A 31.5 A
at 240 V 24.0 A 28.9 A
AC recommended min. overcurrent protection
at 208 V 35.0 A 45.0 A
at 220 V 35.0 A 40.0 A
at 240 V 30.0 A 40.0 A
Max. output residual current per duration 43.1 A/158.4 ms
Nominal frequency 50/60 Hz
Total harmonic distortion < 1.5% < 1.75%
Power factor (cos phi) 0 - 1 ind./cap.
3)
General Data
Maximum efficiency 97.00%
CEC efficiency
at 208 V 96.50% 96.50%
at 220 V
at 240 V 96.50% 96.50%
Cooling Controlled forced-air ventilation
Protection class NEMA 4X
Dimensions h x w x d
28.5 x 20.1 x 8.9 in.
725 x 510 x 225 mm
Weight (full/lite version) 90.4/89.5 lbs. (41.0/40.6 kg)
Permissible ambient temperature -40°F to +140°F (-40°C to +60°C)
