183
EN
The wire-feed unit for the TPS 2700 is integrated in the power source.
1)
connected to public grid at 230/400 V and 50 Hz
2)
PCC = Interface to the public grid
3)
d.c. = Duty cycle
TPS 3200
Dimensions l x w x h 641.5 x 297.4 x 476.5 mm
25.26 x 11.71 x 18.76 in.
Weight 27 kg
59.5 lb.
Supply voltage in wire-feed unit 55 V DC
Nominal current in wire-feed unit 4 A
Wire feed speed 0.5 - 22 m/min
19.69 - 866.14 ipm
Wirespool types all standardised wirespools
Max. permitted wirespool weight 16 kg
35.27 lb
Wirespool diameter 300 mm
11.81 in.
Wire diameter 0.8 - 1.6 mm
0.03 - 0.06 in.
Drive 4 roller drive
Maximum shielding gas pressure 7 bar
101 psi.
Mains voltage 3 x 400 V
Mains voltage tolerance +/- 15 %
Mains frequency 50 / 60 Hz
Mains fuse protection 35 A slow-blow
Mains connection
1)
Restrictions possible
Primary continuous current 100% d.c.
2)
12.6 - 16.7 A
Primary continuous power 8.7 - 11.5 kVA
Cos phi 0.99
Efficiency 91 %
Welding current range
MIG/MAG 3 - 320 A
Rod electrode 10 - 320 A
TIG 3 - 320 A
Welding current at
10 min / 40 °C (104 °F) 40 % d.c.
2)
320 A
60 % d.c.
2)
260 A
100% d.c.
2)
220 A
Welding voltage range according to standard char-
acteristic
MIG/MAG 14.2 - 30.0 V
Rod electrode 20.4 - 32.8 V
TIG 10.1 - 22.8 V
Max. welding voltage (320 A) 52.1 V
