Unit: s
Setting range: 5 - 25
Factory setting: 10
IMPORTANT! Every time the power source is switched on, the cooling unit car-
ries out a test run for 180 seconds.
r Welding circuit resistance (in mOhm)
See the section "Measuring the welding circuit resistance r" from page 112.
L Welding circuit inductivity (in microhenrys)
See the section "Displaying the welding circuit inductivity L" from page 114.
EnE Electrical energy of the arc in relation to the welding speed
Unit: kJ
Setting range: On / OFF
Factory setting: OFF
Since the full range of values (1 kJ - 99999 kJ) cannot be displayed on the three-
digit display, the following display format has been selected:
Value in kJ / indicator on display:
1 to 999 / 1 to 999
1000 to 9999 / 1.00 to 9.99 (without unit digit, e.g., 5270 kJ -> 5.27)
10000 to 99999 / 10.0 to 99.9
(without unit or tens digit, e.g., 23580 kJ -> 23.6)
ALC Correction of the arc length via the welding voltage
Only for MIG/MAG synergic welding
Setting range: On / OFF
Factory setting: OFF
The arc length depends on the welding voltage. The welding voltage can be indi-
vidually adjusted in synergic operation.
If the ALC parameter is set to "OFF", individual adjustment of the welding voltage
is not possible. The welding voltage adjusts automatically according to the selec-
ted welding current or wire speed. When the arc length correction is adjusted, the
voltage changes while the welding current rand the wire speed remain constant.
When adjusting the arc length correction using the selection wheel, the left dis-
play is used for the correction value of the arc length. On the right display, the
value for the welding voltage changes at the same time. The left display then
shows the original value again, e.g., welding current.
Parameters for
MIG/MAG stand-
ard manual weld-
ing in Setup
menu 2nd level
SEt Country-specific setting (Standard/USA) ... Hour/US
Unit:
Setting range: Std, US (Standard/USA)
Factory setting:
Standard version: Std (dimensions: cm / mm)
USA version: US (dimensions: in.)
C-C Cooling unit control
(only when the cooling unit is connected)
109
EN-US
