Fronius TransSteel 3000c Pulse - Feed Roller Installation and Replacement

Inserting/chan-
ging feed rollers
CAUTION!
Danger due to feed roller holders shooting upwards.
Serious injuries may result.
▶
When unlocking the clamping lever, keep fingers away from the area to the left and
right of the clamping lever.
2
1
4
4
5
6
3
1
6
3
31
2
4
5
7
2
CAUTION!
Danger due to open feed rollers.
Serious injuries may result.
▶
After inserting/changing the feed rollers, always install the protective cover of the 4-
roller drive.
