Manual Metal Arc Welding
Safety
WARNING!
Operating the device incorrectly can cause serious injury and damage to property.
▶
Do not use the functions described here until you have fully read and understood the
Operating Instructions.
▶
Do not use the functions described here until you have fully read and understood all
of the Operating Instructions of the system components, especially the safety rules.
WARNING!
An electric shock can be fatal.
If the unit is connected to the grid during installation, there is a danger of serious injury
and damage to property.
▶
Only carry out work on the device if the power switch is in the - O - position.
▶
Only carry out work on the device when it has been disconnected from the grid.
Preparation
1
Set the power switch to - O -
2
Unplug mains plug
IMPORTANT! Check the rod electrode packaging to determine whether the rod elec-
trodes are for (+) or (-) welding.
3
Depending on the type of electrode, insert the grounding cable into the (-) current
socket or into the (+) current socket and twist it clockwise to lock
4
Connect the other end of the grounding cable to the workpiece
5
Depending on the type of electrode, insert the bayonet connector of the electrode
holder cable into the free current socket with opposite polarity and twist it clockwise
to lock
6
Insert mains plug
89
EN-US
