General
General If the Easy Documentation option is available on the power source, the most important
welding data for each welding operation can be documented and saved as a CSV file on
a USB thumb drive.
A Fronius signature is stored with the welding data, which can be used to check and
guarantee the authenticity of the data.
Easy Documentation is activated / deactivated by plugging / unplugging the supplied
Fronius USB thumb drive with FAT32 formatting into the back of the power source.
IMPORTANT! To document the welding data, the date and time must be set correctly.
Documented
welding data
The following data are documented:
Device type
File name
Part number
Serial number
Firmware version of power source
Firmware of PC board DOCMAG (Easy Documentation)
Document version
https://www.easydocu.weldcube.com (A PFDF report of selected welding data can be
created under this link)
Nr. Meter
Start by plugging in the USB thumb drive;
when switching the power source off and on, the meter continues at the
last weld seam number.
A new CSV file is created after 1000 welding operations.
Date Date yyyy-mm-dd
Time Time hh:mm:ss
at the start of current flow
Duration Duration in [s]
from start of current flow to end of current (current flow signal)
I Welding current * in [A]
U Welding voltage * in [V]
vd Wire speed * in [m/min]
wfs Wire speed * in [ipm]
IP Power * from current values in [W]
IE Energy from instantaneous values in [kJ]
over the entire welding operation
I-Mot Motor current * in [A]
Synid Characteristic number
for each welding operation
Job EasyJob number
per weld seam
Process Welding process
95
