APPENDIX A – PROTOTYPE UNITS (built before June 15, 1998)
A.1 Parts List For Prototype Units
A small quantity of units were manufactured before June 1998. The following is a list of
replaceable parts for those units which are not in common with later production models:
HPLA 12 (On/Off Switch)
Part
Number
Description
807-2082 On/Off Switch
807-2512 Resistor 50W 100 ohm *
807-2954 Blower, 115V *
807-2278 Fuse, 20A
807-2447 Fuse Holder
812-1346 Cordset
806-8988 Controller, HPLA
807-2323 UHC Heater Plate, 18”
807-1568 Air RTD Probe
HPLA 12 (Computer)
Part
Number
Description
806-9155 Cowl Assembly
807-3002 Plate, Heater 12”
910-8138 Bumper, HPLA 18 Burger
806-9198 Computer Assembly, HLA
807-0067 Terminal Block (8-pin)
807-3020 Cordset
HPLA 18
Part
Number
Description
807-2278 Fuse, 20A
807-3020 Cordset, HLZ
812-1346 Cordset
807-2512 Resistor, 50W 100 ohm *
807-2954 Blower, HPLA 115V *
806-8988 Controller, HPLA
807-3005 Plate Heater, 18” HPLA24
807-2880 UHC Plate Heater 18”
806-9239 Plate Heater, 12” * *
806-9253 Bumper, Burger
807-0067 Terminal Block (8-pin)
806-9198 Computer, HLA
806-9155 Cowl Assembly
* Replace these components with PN
807-2953, Blower 208/240V.
Remove resistor assembly as it is no
longer needed if a 208V Blower is
used.
** Correct resistance for this Plate
Heater is 230 (±15) ohms.
