H: High performance functions
Function code
Name Setting range
Min.
unit
Factory
setting
Change during
operation
RS485
Data
format
User setting
H01 Total operation time Monitor only 10h 0 - 0
H02 Trip history Monitor only - ---- -
H03
Data initializing
(Data reset)
0: Manual set value
1: Return to factory set value
1 0 X 0
H04 Auto-reset (Times) 0: Inactive 1 to 10 times 1 time 0 0
H05 (Reset interval) 2 to 20s 1s 5 0
H06 Fan stop operation
0: Inactive
1: Active
1 0 0
H07
ACC/DEC pattern
(Mode select).
0: Linear acceleration/deceleration
1: S-curve acceleration/deceleration
(weak)
2: S-curve acceleration/deceleration
(strong)
3: Non-linear
1 0 X 0
H09
Start mode
(Rotating motor
pickup mode)
0: Inactive
1: Active (only when Auto-restart after
momentary power failure mode)
2: Active(All start mode)
1 1 X 0
H10
Energy-saving
operation
0: Inactive
1: Active
1 0 0
H11 Dec mode
0: Normal
1: Coast-to-stop
1 0 0
H12
Instantaneous
overcurrent limiting
0: Inactive
1: Active
1 1 X 0
H13
Auto-restart
(Restart time)
0.1 to 5.0s 0.1s 0.1 X 2
H14 (Frequency fall rate) 0.00 to 100.0Hz/s 0.01Hz/s 10.00 4
H20
PID control
(Mode select)
0: Inactive
1: Forward operation
2: Reverse operation
1 0 X 0
H21 (Feedback signal)
0: Terminal 12 (0 to +10 Vdc) input
1: Terminal C1 (4 to 20 mA) input
2: Terminal 12 (+10 to 0 Vdc) input
3: Terminal C1 (20 to 4 mA) input
1 1 X 0
H22 P (Gain) 0.01 to 10.00 times (1 to 1000%) 0.01 time 0.10 4
H23 I (Integral time)
0.0: Inactive
0.1 to 3600s
0.1s 0.0 2
H24 D (Differential time)
0.00: Inactive
0.01 to 10.0s
0.01s 0.00 4
H25 (Feedback filter) 0.0 to 60.0s 0.1s 0.5 2
H26
PTC thermistor
(Mode select)
0: Inactive
1: Active
1 0 0
H27 (Level) 0.00～5.00V 0.01V 1.60 4
H28 Droop operation -9.9～0.0Hz 0.1Hz 0.0 3
