Fuji Electric FVR-E11S-7EN

5-9
A: Alternative motor parameters
Function code
Name Setting range
Min.
unit
Factory
setting
Change during
operation
RS485
Data
format
User setting
A01 Maximum frequency 2 50 to 400Hz 1Hz 50 X 0
A02 Base frequency 2 25 to 400Hz 1Hz 50 X 0
A03
Rated voltage 2
(at base frequency 2)
0V, 80 to 240V(200V class)
0V,160 to 480V(400V class)
1V
230
400
X 0
A04
Maximum voltage 2
(at maximum
frequency 2)
80 to 240V (200V class)
160 to 480V(400V class)
1V
230
400
X 0
A05 Torque boost 2 0,1,2,3 to 31 1 0 0
A06
Electronic thermal
overload relay
for motor 2 (Select)
0: Inactive
1: Active (for general purpose motors)
2: Active (for inverter motors)
1 1 0
A07 (level) 20 to 135% of the rated inverter current 0.01A
Fuji’s rated
motor
current
6
A08
(Thermal time
constant)
0.5 to 10 min. 0.1min 5.0 2
A09
Torque vector control
2
0:Inactive
1:Active
1 0 X 0
A10 Number of motor 2
poles
2 to 14
2
4 X 0
A11 Motor 2 (Capacity)
0.01 to 5.5kW (4.0kW or smaller)
0.01 to 11.00kW(5.5/7.5kW)
0.01kW
Nominal
applied
motor kW
X 4
A12 (Rated current) 0.00 to 99.9A 0.01A
Fuji's
standard
rating
X 6
A13 (Tuning)
0: Inactive
1: Active (%R1, %X)
2: Active (%R1, %X, Io)
1 0 X 12
A14 (Online tuning) 0: Inactive, 1: Active 1 0 X 0
A15 (No-load current)
0.00 to 99.9A
0.01A
Fuji's
standard
rating
X 6
A16 （％R1 setting）
0.00 to 50.00%
0.01%
Fuji's
standard
rating
4
A17 （％X setting）
0.00 to 50.00%
0.01%
Fuji's
standard
rating
4
A18
(Slip compensation
control 2)
0.00 to 15.00Hz
0.01Hz 0.00 4
A19
(Slip compensation
response time 2)
0.01 to 10.00s
0.01s 0.50 4
Description of change during operation
: The data changed by the or key takes effect on the inverter operation. However, press the
key to store the new data.
: Press the or key to change the data. The new data takes effect after the key is pressed to
store the data.
X : The data can be changed only while the inverter is stopped.
