Stapler Faults
633
Problem Solving
15
1 Make sure that the machine has stopped
before opening the right cover of the finisher.
2 Hold the R1 at the position shown in the figure.
3 Pull out the unit.
Note • After removing the unit, check the inside of
the finisher for any remaining staples.
4 Open the unit as shown in the figure and
remove the jammed staple.
5 Push the removed unit back to the original
position.
6 Close the right cover of the finisher.
Note • A message will be displayed and the machine will not operate if the front cover of the finisher is
even slightly open.
If the staples cannot be removed after carrying out the above procedures, contact our
Customer Support Center.
Be careful in removing jammed staples.
To Next Page
