Color monitor 21P3
14 - English A26361-K618-Z100-2-5E19
Adjusting horizontal size and position
Calling the ADJUST HORIZONTAL setting window
Horizontal picture position (ADJUST POSITION): Shifting the picture to the left or to
the right
Horizontal picture size (ADJUST SIZE): Making the picture narrower or wider
Adjusting vertical size and position
Calling the ADJUST VERTICAL setting window
Vertical picture position (ADJUST POSITION): Shifting the picture down or up
ADJUST SIZE: Making the picture shorter or longer
Correcting picture edges and picture rotation
Calling the ADJUST SHAPE setting window
Pincushion distortion (ADJUST SIDE CURVE):
Correcting symmetrical pincushion distortion (PINCUSHION)
Pincushion distortion is when the sides of the screen display are bent
inward or outward.
Correcting unsymmetrical pincushion distortion (BALANCED)
Unsymmetrical pin balance is when the sides of the screen displays
are bent inward or outward on one side.
Trapezoid/parallelogram distortion (ADJUST SIDE ANGLES):
Correcting trapezoid distortion (TRAPEZOID)
Trapezoid distortion is when the top or bottom of the screen display is
too wide or too narrow.
Correcting parallelogram distortion (PARALLELOGRAM)
Parallelogram distortion means that the sides of the picture bend to the
left or right.
Correcting picture rotation (ADJUST SIDE ANGLES)
Tilt distortion must be set when the screen display is not axially symmetrical.
