Color monitor 21P3
A26361-K618-Z100-2-5E19 English - 13
Ê Press the
OK
button to select the highlighted icon.
The corresponding setting window (here: ADJUST HORIZONTAL) is displayed.
Ê Press the or button to adjust the selected function (here ADJUST POSITION).
Ê Press the key or to mark another function or press the key
OK
to return to the main
menu.
Ê Select the symbol (CLOSE MAIN CONTROLS) in the main menu and press the key
OK
to exit
the OSD menu.
All changes are stored automatically.
If you want to change other settings, select the corresponding function from the OSD main menu. All
possible adjustments of the main menu are described in the following.
Setting language for the OSD menu
Setting language for the OSD menu (LANGUAGE)
You can choose from English (default setting), German, French, Italian and
Spanish.
Setting video signal to BNC or D-SUB
Setting video signal to BNC or D-SUB (INPUT SIGNAL SELECTION)
INPUT A = The signal supplied via the D-SUB connection is fed in.
INPUT B = The signal supplied via the BNC connections is fed in.
i
You can also change the video signal by simultaneously pressing the keys
OK
and
(INPUT A/B).
Adjusting proportional picture size
Adjusting proportional picture size (ZOOM)
With this function you can zoom the picture in or out while retaining the side ratios.
The picture zoom adjustment will stop as soon as either the horizontal or vertical
size reaches its maximum or minimum value.
