Ports and operating elements
This chapter presents the individual hardware components of your notebook. It provides an overview
of the notebook’s displays and ports. Please familiarise yourself with these components before you
start to work with your notebook.
19
20
7
8
9
14
15
11
16
17
5
1
12
13
10
4
2
3
18
6
11 = Built-in loudspeakers
1 = Modem port
12 = Status indicators
2 = Kensington Lock
13 = LAN port
3 = CD/DVD drive
14 = Monitor port
4 = USB port
15 = DC IN jack
5 = USB port
16 = Battery release
6 = Power switch for the notebook:
17 = Battery
7 = Touchpad
18 = Battery release
8 = Touchpad buttons
19 = Service compartment (hard disk)
9 = Microphone port
20 = Service compartment (memory)
10 = Headphone port
(speaker port)
10600803307, edition 1 3
