Removing and installing components
during servicing
!
Only qualified technicians should repair your notebook. Unauthorised opening or incorrect
repair may greatly endanger the user (electric shock, fire risk) and will invalidate your
warranty.
You may remove and install the components described in this chapter yourself after consulting the
Hotline/Help Desk.
If you remove and install components without consulting the Hotline/Help Desk, then the
warranty of your notebook will be voided.
!
Notes on installing and removing boards and
components
● Switch the notebook off and pull the power plug out of the mains socket.
● Remove the battery.
● Take care when you use the locking mechanisms on the battery and any other component.
● Never use sharp objects such as screwdrivers, scissors or knives as leverage to remove
covers.
Boards with electrostatic sensitive devices (ESD) are marked with the label
shown.
When handling boards carrying ESDs, you must always observe the
following points:
● You must always discharge static build up (e.g. by touching a
grounded object) before working.
● The equipment and tools you use must be free of static charges.
● Remove the power plug from the mains supply before inserting or
removing boards containing ESDs.
● Always hold boards with ESDs by their edges.
● Never touch pins or conductors on boards carrying ESDs.
10600803307, edition 1 47
