Using your notebook
26 10600690568, edition 1
Removing and installing the battery
!
Only use batteries approved by Fujitsu Siemens Computers for your notebook.
Never use force when inserting or removing a battery.
Make sure that no foreign bodies get into the battery connections.
Removing battery
► Switch the notebook off and pull the power plug out of the mains socket.
► Close the LCD screen so that it locks into place.
► Disconnect all cables connected to the notebook.
► Turn your notebook over and place it on a stabile, sturdy, flat surface. If necessary, lay an anti-
slip cloth on this surface to prevent the notebook from being scratched.
1
2
3
► Push the battery lock (1) in the direction of the arrow.
► Slide the battery lock in the direction of the arrow (2) and hold it in place.
► Remove the battery from the battery compartment (3).
Inserting battery
1
2
► Push the battery (1) into the battery compartment until it engages.
► Push the battery lock (2) in the direction of the arrow.
