Removing and installing components during servicing
56 10600690568, edition 1
Removing and installing the battery
i
How to remove and reinstall a battery is described in chapter "Using your notebook", in the
section "Removing and installing the battery".
Removing and installing the hard disk
Removing the hard disk
► Switch the notebook off and pull the power plug out of the mains socket.
► Close the LCD screen so that it locks into place.
► Disconnect all cables connected to the notebook.
► Turn your notebook over and place it on a stabile, sturdy, flat surface. If necessary, lay an anti-
slip cloth on this surface to prevent the notebook from being scratched.
► Remove the battery (see "Removing and installing the battery").
1
1
1
1
1
2
2
► Remove the screws (1).
► Remove the cover off the notebook in the direction of the arrow (2).
