103
Mounting instruction
   
TO BATTERY+12V (Permanent Supply)
TO POWER ANTENNA RELAY (Supply)
TO HEADLIGHT SWITCH (Illumination)
TO TURN-ON LEAD OF EACH UNIT (Supply)
Red
Yellow
Blue
Orange/White
Blue/White
Black
TO ACC (Power Supply)
1
DIGITAL OUT
TO GROUND
Pink
Purple/Black
Purple
Green/Black
Green
Gray/Black
White/Black
White
16P
ANTENNA PLUG
CD5441
Gray
FL FR RL RR
3
2
4
5
6
13
CELLULAR PHONE (For mute)
12
14
NON-FADER
10
FRONT
8 9
REAR
CD5441 Receiver, used alone
1)
INTERCONNECTING CABLE
12
MP3 unit
15
