Mounting instruction
104
TO POWER ANTENNA RELAY (Supply)
TO HEADLIGHT SWITCH (Illumination)
TO TURN-ON LEAD OF EACH UNIT (Supply)
TO ACC (Power Supply)
1
TO BATTERY+12V
(Permanent Supply)
2
TO GROUND
Pink
Purple/BlackBlack
Purple
Green/Black
Blue/White
Orange/White
Blue Red
Yellow
Green
Gray/Black
White/Black
White
13P
13P 16P
CD5441
2P
ANTENNA PLUG
5083
Gray
3
4
5
6
CELLULAR PHONE (For mute)
12
NON-FADER
10
DIGITAL OUT
13
INTERCONNECTING CABLE
12
TO SIGNAL INPUT OF AUXILIARY POWER AMPLIFIER
INSULATE EACH WIRE WITH TAPE INSULATE EACH WIRE WITH TAPE
CD5441+ 5083 + Power Amplifier
2)
14
MP3 unit
15
