144
Note: Be careful because the bar nut for the hinge may fall out when the M6 hexagon socket
set screw is loosened.
Model 2724/2737/2742
Model 2616/2624
M6 screw
M6 screws
Rack-side hinge
M6 hexagon socket
set screw
Bar nut for hinge
Model 2642
M5 flat head screws
Lock plate
M5 core
spring nuts
Lock plate
M6 core
spring nut
