　　4　Handling the Rack after Installation　　183
E
3 From the rear, secure the mounting plate, the rack, and the stabilizer body
with M5 flat head screws.
4 Fully tighten the M5 flat head screws on the front.
M5 flat head
screws
Mounting plate
(Rear)
