Removing an d installing components
during servicing
Removing and installing the har
ddisk
Removing a cover
1
1
1
2
► Remove the screws (1).
Keepthescrewsinasa
fe place. If you are removing more than one component at
the sam e time, store t
he screws for the ind ividual components separate from each
other. If y ou instal
l the wrong screws, components may be damaged.
► Slide the cover in the direction of the arrow (2), and lift it away from the notebook.
Fujitsu Technology Solutions 61
