Fujitsu AB G36LRTE Series User Manual

¢
Heating capacity (Double twin)

Compact cassette type
Model: AUYG22LVLA × 4
AFR
m
3
/h
3,720
Indoor temperature
°CDB 16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-20 -21 12.77 6.49 12.47 6.62 12.16 6.76 11.86 6.89 11.56 7.02
-15 -16 19.57 7.49 19.11 7.64 18.64 7.80 18.18 7.95 17.72 8.11
-10 -11 22.81 7.95 22.27 8.12 21.73 8.28 21.19 8.45 20.65 8.61
-5 -7 25.33 8.29 24.73 8.47 24.12 8.64 23.52 8.81 22.92 8.98
0 -2 27.31 8.38 26.66 8.55 26.00 8.73 25.35 8.90 24.71 9.06
5 3 30.86 8.40 30.12 8.57 29.39 8.75 28.65 8.91 27.92 9.05
7 6 31.19 8.41 30.44 8.58 29.70 8.76 28.96 8.93 28.22 9.05
10 8 32.64 8.35 31.86 8.52 31.08 8.70 30.29 8.87 29.53 9.05
15 10 33.88 8.35 33.07 8.51 32.26 8.69 31.45 8.87 30.65 9.00
20 15 30.48 7.28 29.75 7.42 29.02 7.58 28.30 7.74 27.57 7.84
24 18 31.16 7.25 30.42 7.39 29.67 7.54 28.93 7.70 28.20 7.80

Duct type
Model: ARYG22LMLA × 4
AFR
m
3
/h
4,400
Indoor temperature
°CDB 16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-20 -21 12.77 6.85 12.47 6.98 12.16 7.13 11.86 7.27 11.56 7.40
-15 -16 19.57 7.90 19.11 8.06 18.64 8.23 18.18 8.39 17.72 8.55
-10 -11 22.81 8.39 22.27 8.56 21.73 8.74 21.19 8.91 20.65 9.09
-5 -7 25.33 8.75 24.73 8.93 24.12 9.11 23.52 9.29 22.92 9.47
0 -2 27.31 8.84 26.66 9.02 26.00 9.21 25.35 9.39 24.71 9.56
5 3 30.86 8.86 30.12 9.04 29.39 9.23 28.65 9.40 27.92 9.54
7 6 31.19 8.87 30.44 9.05 29.70 9.24 28.96 9.42 28.22 9.55
10 8 32.64 8.81 31.86 8.98 31.08 9.18 30.29 9.35 29.53 9.55
15 10 33.88 8.81 33.07 8.98 32.26 9.17 31.45 9.36 30.65 9.49
20 15 30.48 7.68 29.75 7.83 29.02 8.00 28.30 8.17 27.57 8.27
24 18 31.16 7.64 30.42 7.79 29.67 7.96 28.93 8.13 28.20 8.23

Floor/Ceiling type
Model: ABYG22LVTA × 4
AFR
m
3
/h
3,920
Indoor temperature
°CDB 16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-20 -21 12.77 6.49 12.47 6.62 12.16 6.76 11.86 6.89 11.56 7.02
-15 -16 19.57 7.49 19.11 7.64 18.64 7.80 18.18 7.95 17.72 8.11
-10 -11 22.81 7.95 22.27 8.12 21.73 8.28 21.19 8.45 20.65 8.61
-5 -7 25.33 8.29 24.73 8.47 24.12 8.64 23.52 8.81 22.92 8.98
0 -2 27.31 8.38 26.66 8.55 26.00 8.73 25.35 8.90 24.71 9.06
5 3 30.86 8.40 30.12 8.57 29.39 8.75 28.65 8.91 27.92 9.05
7 6 31.19 8.41 30.44 8.58 29.70 8.76 28.96 8.93 28.22 9.05
10 8 32.64 8.35 31.86 8.52 31.08 8.70 30.29 8.87 29.53 9.05
15 10 33.88 8.35 33.07 8.51 32.26 8.69 31.45 8.87 30.65 9.00
20 15 30.48 7.28 29.75 7.42 29.02 7.58 28.30 7.74 27.57 7.84
24 18 31.16 7.25 30.42 7.39 29.67 7.54 28.93 7.70 28.20 7.80
- 164 -
6-2. Model: AOYG90LRLA 6. Capacity table
OUTDOOR UNIT AOYG72-90LRLA OUTDOOR UNIT AOYG72-90LRLA

Fujitsu AB G36LRTE Series Specifications
