8-5. Outdoor unit
¢
Local setting switch buttons

Control PCB and switch buttons location
Control PCB of the outdoor unit is located as shown in the following figure.
LED display and button
- 279 -
8-5. Outdoor unit 8. Function settings
SYSTEM
DESIGN
SYSTEM
DESIGN
