Fujitsu AGU12RLF Design & Technical Manual

¢
Model: AOU45RLXFZ
 Heating
Combination of indoor unit
Type of in-
door unit
Rated capacity for each indoor
unit [kBtu/h]
Maximum capacity for each in-
door unit [kBtu/h]
Total capacity
[kBtu/h]
Input power [kW]
Unit
Total
Unit Unit
Min. Rated Max. Min. Rated Max.
1 2 3 4 5 1 2 3 4 5 1 2 3 4 5
12 24 — — — 36 Non-ducted 12.8 25.6 — — — 14.4 28.8 — — — 12.0 38.4 43.2 0.70 3.24 3.39
15 24 — — — 39 Non-ducted 16.0 25.6 — — — 18.0 28.8 — — — 12.0 41.6 46.8 0.70 3.53 3.70
18 18 — — — 36 Non-ducted 19.2 19.2 — — — 21.6 21.6 — — — 12.0 38.4 43.2 0.70 3.24 3.39
18 24 — — — 42 Non-ducted 19.2 25.6 — — — 21.6 28.8 — — — 12.0 44.8 50.4 0.70 3.83 4.01
24 24 — — — 48 Non-ducted 24.0 24.0 — — — 27.0 27.0 — — — 12.0 48.0 54.0 0.70 4.13 4.32
7 7 24 — — 38 Non-ducted 7.5 7.5 25.6 — — 8.4 8.4 28.8 — — 12.0 40.5 45.6 0.70 3.36 3.60
7 9 18 — — 34 Non-ducted 7.5 9.6 19.2 — — 8.4 10.8 21.6 — — 12.0 36.3 40.8 0.70 2.98 3.19
7 9 24 — — 40 Non-ducted 7.5 9.6 25.6 — — 8.4 10.8 28.8 — — 12.0 42.7 48.0 0.70 3.56 3.80
7 12 18 — — 37 Non-ducted 7.5 12.8 19.2 — — 8.4 14.4 21.6 — — 12.0 39.5 44.4 0.70 3.27 3.49
7 12 24 — — 43 Non-ducted 7.5 12.8 25.6 — — 8.4 14.4 28.8 — — 12.0 45.9 51.6 0.70 3.85 4.12
7 15 15 — — 37 Non-ducted 7.5 16.0 16.0 — — 8.4 18.0 18.0 — — 12.0 39.5 44.4 0.70 3.27 3.49
7 15 18 — — 40 Non-ducted 7.5 16.0 19.2 — — 8.4 18.0 21.6 — — 12.0 42.7 48.0 0.70 3.56 3.80
7 15 24 — — 46 Non-ducted 7.3 15.7 25.0 — — 8.2 17.6 28.2 — — 12.0 48.0 54.0 0.70 4.04 4.32
7 18 18 — — 43 Non-ducted 7.5 19.2 19.2 — — 8.4 21.6 21.6 — — 12.0 45.9 51.6 0.70 3.85 4.12
7 18 24 — — 49 Non-ducted 6.9 17.6 23.5 — — 7.7 19.8 26.4 — — 12.0 48.0 54.0 0.70 4.04 4.32
9 9 18 — — 36 Non-ducted 9.6 9.6 19.2 — — 10.8 10.8 21.6 — — 12.0 38.4 43.2 0.70 3.17 3.39
9 9 24 — — 42 Non-ducted 9.6 9.6 25.6 — — 10.8 10.8 28.8 — — 12.0 44.8 50.4 0.70 3.75 4.01
9 12 15 — — 36 Non-ducted 9.6 12.8 16.0 — — 10.8 14.4 18.0 — — 12.0 38.4 43.2 0.70 3.17 3.39
9 12 18 — — 39 Non-ducted 9.6 12.8 19.2 — — 10.8 14.4 21.6 — — 12.0 41.6 46.8 0.70 3.46 3.70
9 12 24 — — 45 Non-ducted 9.6 12.8 25.6 — — 10.8 14.4 28.8 — — 12.0 48.0 54.0 0.70 4.04 4.32
9 15 15 — — 39 Non-ducted 9.6 16.0 16.0 — — 10.8 18.0 18.0 — — 12.0 41.6 46.8 0.70 3.46 3.70
9 15 18 — — 42 Non-ducted 9.6 16.0 19.2 — — 10.8 18.0 21.6 — — 12.0 44.8 50.4 0.70 3.60 4.01
9 15 24 — — 48 Non-ducted 9.0 15.0 24.0 — — 10.1 16.9 27.0 — — 12.0 48.0 54.0 0.70 3.88 4.32
9 18 18 — — 45 Non-ducted 9.6 19.2 19.2 — — 10.8 21.6 21.6 — — 12.0 48.0 54.0 0.70 3.88 4.32
9 18 24 — — 51 Non-ducted 8.5 16.9 22.6 — — 9.5 19.1 25.4 — — 12.0 48.0 54.0 0.70 3.88 4.32
12 12 12 — — 36 Non-ducted 12.8 12.8 12.8 — — 14.4 14.4 14.4 — — 12.0 38.4 43.2 0.70 3.04 3.39
12 12 15 — — 39 Non-ducted 12.8 12.8 16.0 — — 14.4 14.4 18.0 — — 12.0 41.6 46.8 0.70 3.32 3.70
12 12 18 — — 42 Non-ducted 12.8 12.8 19.2 — — 14.4 14.4 21.6 — — 12.0 44.8 50.4 0.70 3.44 4.01
12 12 24 — — 48 Non-ducted 12.0 12.0 24.0 — — 13.5 13.5 27.0 — — 12.0 48.0 54.0 0.70 3.88 4.32
12 15 15 — — 42 Non-ducted 12.8 16.0 16.0 — — 14.4 18.0 18.0 — — 12.0 44.8 50.4 0.70 3.60 4.01
12 15 18 — — 45 Non-ducted 12.8 16.0 19.2 — — 14.4 18.0 21.6 — — 12.0 48.0 54.0 0.70 3.88 4.32
12 15 24 — — 51 Non-ducted 11.3 14.1 22.6 — — 12.7 15.9 25.4 — — 12.0 48.0 54.0 0.70 3.88 4.32
12 18 18 — — 48 Non-ducted 12.0 18.0 18.0 — — 13.5 20.3 20.3 — — 12.0 48.0 54.0 0.70 4.04 4.32
12 18 24 — — 54 Non-ducted 10.7 16.0 21.3 — — 12.0 18.0 24.0 — — 12.0 48.0 54.0 0.70 4.04 4.32
15 15 15 — — 45 Non-ducted 16.0 16.0 16.0 — — 18.0 18.0 18.0 — — 12.0 48.0 54.0 0.70 4.04 4.32
15 15 18 — — 48 Non-ducted 15.0 15.0 18.0 — — 16.9 16.9 20.3 — — 12.0 48.0 54.0 0.70 4.04 4.32
15 15 24 — — 54 Non-ducted 13.3 13.3 21.3 — — 15.0 15.0 24.0 — — 12.0 48.0 54.0 0.70 4.04 4.32
15 18 18 — — 51 Non-ducted 14.1 16.9 16.9 — — 15.9 19.1 19.1 — — 12.0 48.0 54.0 0.70 4.04 4.32
18 18 18 — — 54 Non-ducted 16.0 16.0 16.0 — — 18.0 18.0 18.0 — — 12.0 48.0 54.0 0.70 4.04 4.32
7 7 7 15 — 36 Non-ducted 7.5 7.5 7.5 16.0 — 8.4 8.4 8.4 18.0 — 12.0 38.4 43.2 0.70 3.11 3.39
7 7 7 18 — 39 Non-ducted 7.5 7.5 7.5 19.2 — 8.4 8.4 8.4 21.6 — 12.0 41.6 46.8 0.70 3.39 3.70
7 7 7 24 — 45 Non-ducted 7.5 7.5 7.5 25.6 — 8.4 8.4 8.4 28.8 — 12.0 48.0 54.0 0.70 3.96 4.32
7 7 9 12 — 35 Non-ducted 7.5 7.5 9.6 12.8 — 8.4 8.4 10.8 14.4 — 12.0 37.3 42.0 0.70 3.01 3.29
7 7 9 15 — 38 Non-ducted 7.5 7.5 9.6 16.0 — 8.4 8.4 10.8 18.0 — 12.0 40.5 45.6 0.70 3.29 3.60
7 7 9 18 — 41 Non-ducted 7.5 7.5 9.6 19.2 — 8.4 8.4 10.8 21.6 — 12.0 43.7 49.2 0.70 3.58 3.91
7 7 9 24 — 47 Non-ducted 7.1 7.1 9.2 24.5 — 8.0 8.0 10.3 27.6 — 12.0 48.0 54.0 0.70 3.96 4.32
7 7 12 12 — 38 Non-ducted 7.5 7.5 12.8 12.8 — 8.4 8.4 14.4 14.4 — 12.0 40.5 45.6 0.70 3.29 3.60
7 7 12 15 — 41 Non-ducted 7.5 7.5 12.8 16.0 — 8.4 8.4 14.4 18.0 — 12.0 43.7 49.2 0.70 3.58 3.91
7 7 12 18 — 44 Non-ducted 7.5 7.5 12.8 19.2 — 8.4 8.4 14.4 21.6 — 12.0 46.9 52.8 0.70 3.86 4.22
7 7 12 24 — 50 Non-ducted 6.7 6.7 11.5 23.0 — 7.6 7.6 13.0 25.9 — 12.0 48.0 54.0 0.70 3.96 4.32
7 7 15 15 — 44 Non-ducted 7.5 7.5 16.0 16.0 — 8.4 8.4 18.0 18.0 — 12.0 46.9 52.8 0.70 3.86 4.22
7 7 15 18 — 47 Non-ducted 7.1 7.1 15.3 18.4 — 8.0 8.0 17.2 20.7 — 12.0 48.0 54.0 0.70 3.88 4.32
7 7 15 24 — 53 Non-ducted 6.3 6.3 13.6 21.7 — 7.1 7.1 15.3 24.5 — 12.0 48.0 54.0 0.70 3.88 4.32
7 7 18 18 — 50 Non-ducted 6.7 6.7 17.3 17.3 — 7.6 7.6 19.4 19.4 — 12.0 48.0 54.0 0.70 3.88 4.32
7 9 9 9 — 34 Non-ducted 7.5 9.6 9.6 9.6 — 8.4 10.8 10.8 10.8 — 12.0 36.3 40.8 0.70 2.86 3.19
7 9 9 12 — 37 Non-ducted 7.5 9.6 9.6 12.8 — 8.4 10.8 10.8 14.4 — 12.0 39.5 44.4 0.70 3.14 3.49
7 9 9 15 — 40 Non-ducted 7.5 9.6 9.6 16.0 — 8.4 10.8 10.8 18.0 — 12.0 42.7 48.0 0.70 3.42 3.80
7 9 9 18 — 43 Non-ducted 7.5 9.6 9.6 19.2 — 8.4 10.8 10.8 21.6 — 12.0 45.9 51.6 0.70 3.52 4.12
7 9 9 24 — 49 Non-ducted 6.9 8.8 8.8 23.5 — 7.7 9.9 9.9 26.4 — 12.0 48.0 54.0 0.70 3.88 4.32
7 9 12 12 — 40 Non-ducted 7.5 9.6 12.8 12.8 — 8.4 10.8 14.4 14.4 — 12.0 42.7 48.0 0.70 3.42 3.80
7 9 12 15 — 43 Non-ducted 7.5 9.6 12.8 16.0 — 8.4 10.8 14.4 18.0 — 12.0 45.9 51.6 0.70 3.70 4.12
7 9 12 18 — 46 Non-ducted 7.3 9.4 12.5 18.8 — 8.2 10.6 14.1 21.1 — 12.0 48.0 54.0 0.70 3.88 4.32
7 9 12 24 — 52 Non-ducted 6.5 8.3 11.1 22.2 — 7.3 9.3 12.5 24.9 — 12.0 48.0 54.0 0.70 3.96 4.32
7 9 15 15 — 46 Non-ducted 7.3 9.4 15.7 15.7 — 8.2 10.6 17.6 17.6 — 12.0 48.0 54.0 0.70 3.96 4.32
7 9 15 18 — 49 Non-ducted 6.9 8.8 14.7 17.6 — 7.7 9.9 16.5 19.8 — 12.0 48.0 54.0 0.70 3.96 4.32
7 9 18 18 — 52 Non-ducted 6.5 8.3 16.6 16.6 — 7.3 9.3 18.7 18.7 — 12.0 48.0 54.0 0.70 3.96 4.32
7 12 12 12 — 43 Non-ducted 7.5 12.8 12.8 12.8 — 8.4 14.4 14.4 14.4 — 12.0 45.9 51.6 0.70 3.77 4.12
7 12 12 15 — 46 Non-ducted 7.3 12.5 12.5 15.7 — 8.2 14.1 14.1 17.6 — 12.0 48.0 54.0 0.70 3.96 4.32
7 12 12 18 — 49 Non-ducted 6.9 11.8 11.8 17.6 — 7.7 13.2 13.2 19.8 — 12.0 48.0 54.0 0.70 3.96 4.32
7 12 15 15 — 49 Non-ducted 6.9 11.8 14.7 14.7 — 7.7 13.2 16.5 16.5 — 12.0 48.0 54.0 0.70 3.96 4.32
7 12 15 18 — 52 Non-ducted 6.5 11.1 13.8 16.6 — 7.3 12.5 15.6 18.7 — 12.0 48.0 54.0 0.70 3.96 4.32
7 15 15 15 — 52 Non-ducted 6.5 13.8 13.8 13.8 — 7.3 15.6 15.6 15.6 — 12.0 48.0 54.0 0.70 3.96 4.32
9 9 9 9 — 36 Non-ducted 9.6 9.6 9.6 9.6 — 10.8 10.8 10.8 10.8 — 12.0 38.4 43.2 0.70 3.11 3.39
9 9 9 12 — 39 Non-ducted 9.6 9.6 9.6 12.8 — 10.8 10.8 10.8 14.4 — 12.0 41.6 46.8 0.70 3.39 3.70
9 9 9 15 — 42 Non-ducted 9.6 9.6 9.6 16.0 — 10.8 10.8 10.8 18.0 — 12.0 44.8 50.4 0.70 3.67 4.01
9 9 9 18 — 45 Non-ducted 9.6 9.6 9.6 19.2 — 10.8 10.8 10.8 21.6 — 12.0 48.0 54.0 0.70 3.96 4.32
9 9 9 24 — 51 Non-ducted 8.5 8.5 8.5 22.6 — 9.5 9.5 9.5 25.4 — 12.0 48.0 54.0 0.70 3.96 4.32
9 9 12 12 — 42 Non-ducted 9.6 9.6 12.8 12.8 — 10.8 10.8 14.4 14.4 — 12.0 44.8 50.4 0.70 3.67 4.01
9 9 12 15 — 45 Non-ducted 9.6 9.6 12.8 16.0 — 10.8 10.8 14.4 18.0 — 12.0 48.0 54.0 0.70 3.96 4.32
9 9 12 18 — 48 Non-ducted 9.0 9.0 12.0 18.0 — 10.1 10.1 13.5 20.3 — 12.0 48.0 54.0 0.70 3.96 4.32
9 9 12 24 — 54 Non-ducted 8.0 8.0 10.7 21.3 — 9.0 9.0 12.0 24.0 — 12.0 48.0 54.0 0.70 3.96 4.32
9 9 15 15 — 48 Non-ducted 9.0 9.0 15.0 15.0 — 10.1 10.1 16.9 16.9 — 12.0 48.0 54.0 0.70 3.88 4.32
9 9 15 18 — 51 Non-ducted 8.5 8.5 14.1 16.9 — 9.5 9.5 15.9 19.1 — 12.0 48.0 54.0 0.70 3.88 4.32
- 249 -
6-1. Combinations 6. Capacity table
OUTDOOR UNIT AOU45RLXFZ OUTDOOR UNIT AOU45RLXFZ
