Inverter PCB Momentary Power
Failure Detection
OK
OK
OK
OK
Inverter PCB
Check Point 1 : Noise, momentary power failure, voltage drop
Check if temporary voltage drop was not generated.
Check if momentary power failure was not generated.
Check if ground is connection correctly or there are no related cables near the power line.
Check Point 2 : Check the magnetic contactor (for Inverter) coil side wiring
Connector and wiring connection state check
Cable open check
Cable open check
Check Point 3 : Check the wiring (Power supply to Filter PCB (INV) to
Inverter PCB)
Connector and wiring connection state check
Check Point 4 : Check Main PCB
Chack Main PCB. (Refer to "Sarvise Parts Information 4")
>>If replace Main PCB, Refer to 06-03 page Main PCB removal.
Check Point 5 : Replace Inverter PCB
Replace Inverter PCB.
1. Noise, momentary power failure, voltage drop 2. Magnetic Relay (for Inverter) coil side
wiring disconnection, open 3. Power supply to Filter PCB (INV) to Inverter PCB wiring
disconnection, open 4. Main PCB defective 5. Inverter PCB defective
''Momentary power failure" received from Inverter PCB
Indoor Unit : No Display
Outdoor Unit : E. 67. 2
Error Code : 67
04-30
Trouble shooting 22
Indicate or Display:
Detective Actuators:
Detective details:
OUTDOOR UNIT Error Method:
Forecast of Cause :
