OUTDOOR UNIT AOU36RLXFZH
6-3. Heating capacity
 Model: AOU36RLXFZH
NOTE: Values mentioned in the table are calculated based on the maximum capacity.
 Heating capacity in kBtu/h
TC: Total Capacity (kBtu/h), IP: Input Power (kW)
Indoor unit
connecting
capacity
Outdoor temperature
Indoor temperature
60 °FDB 65 °FDB 70 °FDB 75 °FDB 78 °FDB
kBtu/h °FDB °FWB TC IP TC IP TC IP TC IP TC IP
39
-15 -17 23.3 3.46 22.7 3.53 22.1 3.60 21.6 3.67 21.0 3.74
-5 -7 26.4 3.65 25.8 3.72 25.1 3.80 24.5 3.88 23.9 3.95
5 3 38.2 5.08 37.3 5.18 36.4 5.29 35.5 5.40 34.6 5.50
14 12 40.6 5.01 39.6 5.12 38.6 5.22 37.7 5.32 36.7 5.43
23 19 42.9 4.76 41.9 4.86 40.8 4.96 39.8 5.06 38.8 5.16
32 28 44.1 4.57 43.1 4.66 42.0 4.76 41.0 4.86 39.9 4.95
41 37 44.1 3.94 43.1 4.02 42.0 4.10 41.0 4.18 39.9 4.26
47 43 44.1 3.21 43.1 3.28 42.0 3.35 41.0 3.41 39.9 3.48
50 47 44.1 3.20 43.1 3.27 42.0 3.34 41.0 3.40 39.9 3.47
59 50 44.1 3.18 43.1 3.25 42.0 3.31 41.0 3.38 39.9 3.45
68 59 44.1 3.05 43.1 3.11 42.0 3.18 41.0 3.24 39.9 3.30
75 65 44.1 2.95 43.1 3.01 42.0 3.07 41.0 3.13 39.9 3.19
38
-15 -17 23.3 3.46 22.7 3.53 22.1 3.60 21.6 3.67 21.0 3.74
-5 -7 26.4 3.65 25.8 3.72 25.1 3.80 24.5 3.88 23.9 3.95
5 3 38.2 5.08 37.3 5.18 36.4 5.29 35.5 5.40 34.6 5.50
14 12 40.6 5.01 39.6 5.12 38.6 5.22 37.7 5.32 36.7 5.43
23 19 42.9 4.76 41.9 4.86 40.8 4.96 39.8 5.06 38.8 5.16
32 28 44.1 4.57 43.1 4.66 42.0 4.76 41.0 4.86 39.9 4.95
41 37 44.1 3.94 43.1 4.02 42.0 4.10 41.0 4.18 39.9 4.26
47 43 44.1 3.21 43.1 3.28 42.0 3.35 41.0 3.41 39.9 3.48
50 47 44.1 3.20 43.1 3.27 42.0 3.34 41.0 3.40 39.9 3.47
59 50 44.1 3.18 43.1 3.25 42.0 3.31 41.0 3.38 39.9 3.45
68 59 44.1 3.05 43.1 3.11 42.0 3.18 41.0 3.24 39.9 3.30
75 65 44.1 2.95 43.1 3.01 42.0 3.07 41.0 3.13 39.9 3.19
37
-15 -17 23.3 3.46 22.7 3.53 22.1 3.60 21.6 3.67 21.0 3.74
-5 -7 26.4 3.65 25.8 3.72 25.1 3.80 24.5 3.88 23.9 3.95
5 3 38.2 5.08 37.3 5.18 36.4 5.29 35.5 5.40 34.6 5.50
14 12 40.6 5.01 39.6 5.12 38.6 5.22 37.7 5.32 36.7 5.43
23 19 42.9 4.76 41.9 4.86 40.8 4.96 39.8 5.06 38.8 5.16
32 28 44.1 4.57 43.1 4.66 42.0 4.76 41.0 4.86 39.9 4.95
41 37 44.1 3.94 43.1 4.02 42.0 4.10 41.0 4.18 39.9 4.26
47 43 44.1 3.21 43.1 3.28 42.0 3.35 41.0 3.41 39.9 3.48
50 47 44.1 3.20 43.1 3.27 42.0 3.34 41.0 3.40 39.9 3.47
59 50 44.1 3.18 43.1 3.25 42.0 3.31 41.0 3.38 39.9 3.45
68 59 44.1 3.05 43.1 3.11 42.0 3.18 41.0 3.24 39.9 3.30
75 65 44.1 2.95 43.1 3.01 42.0 3.07 41.0 3.13 39.9 3.19
36
-15 -17 23.3 3.45 22.7 3.52 22.1 3.59 21.6 3.66 21.0 3.74
-5 -7 26.4 3.64 25.8 3.72 25.1 3.79 24.5 3.87 23.9 3.94
5 3 38.2 5.07 37.3 5.18 36.4 5.28 35.5 5.39 34.6 5.49
14 12 40.6 5.01 39.6 5.11 38.6 5.21 37.7 5.32 36.7 5.42
23 19 42.9 4.76 41.9 4.86 40.8 4.96 39.8 5.06 38.8 5.16
32 28 44.1 4.57 43.1 4.66 42.0 4.76 41.0 4.85 39.9 4.95
41 37 44.1 3.94 43.1 4.02 42.0 4.10 41.0 4.18 39.9 4.26
47 43 44.1 3.21 43.1 3.28 42.0 3.35 41.0 3.41 39.9 3.48
50 47 44.1 3.20 43.1 3.27 42.0 3.34 41.0 3.40 39.9 3.47
59 50 44.1 3.18 43.1 3.25 42.0 3.31 41.0 3.38 39.9 3.45
68 59 44.1 3.05 43.1 3.11 42.0 3.18 41.0 3.24 39.9 3.30
75 65 44.1 2.95 43.1 3.01 42.0 3.07 41.0 3.13 39.9 3.19
35
-15 -17 22.6 3.35 22.1 3.42 21.5 3.49 21.0 3.56 20.5 3.63
-5 -7 25.6 3.53 25.0 3.61 24.4 3.68 23.8 3.75 23.2 3.83
5 3 37.2 4.92 36.3 5.03 35.4 5.13 34.5 5.23 33.6 5.34
14 12 39.4 4.86 38.5 4.96 37.6 5.06 36.6 5.16 35.7 5.26
23 19 41.7 4.62 40.7 4.71 39.7 4.81 38.7 4.91 37.7 5.00
32 28 42.9 4.44 41.9 4.53 40.8 4.62 39.8 4.71 38.8 4.80
41 37 42.9 3.82 41.9 3.90 40.8 3.98 39.8 4.06 38.8 4.14
47 43 42.9 3.11 41.9 3.18 40.8 3.24 39.8 3.31 38.8 3.37
50 47 42.9 3.11 41.9 3.17 40.8 3.24 39.8 3.30 38.8 3.37
59 50 42.9 3.08 41.9 3.15 40.8 3.21 39.8 3.28 38.8 3.34
68 59 42.9 2.96 41.9 3.02 40.8 3.08 39.8 3.14 38.8 3.20
75 65 42.9 2.86 41.9 2.92 40.8 2.98 39.8 3.04 38.8 3.10
