6-2. Model: AOYG12KHCAN
NOTE: Values mentioned in the table are calculated based on the maximum capacity.
COOLING
Pipe length (m)
5 7.5 10 15 20
Height difference H (m)
Indoor unit is higher than
outdoor unit *1
15 — — — 0.882 0.880
10 — — 0.943 0.896 0.894
7.5 — 0.968 0.947 0.900 0.898
5 0.992 0.972 0.951 0.903 0.901
0 1.000 0.980 0.958 0.911 0.909
Indoor unit is lower than
outdoor unit *2
-5 1.000 0.980 0.958 0.911 0.909
-7.5 — 0.980 0.958 0.911 0.909
-10 — — 0.958 0.911 0.909
-15 — — — 0.911 0.909
HEATING
Pipe length (m)
5 7.5 10 15 20
Height difference H (m)
Indoor unit is higher than
outdoor unit *1
15 — — — 0.952 0.932
10 — — 1.002 0.952 0.932
7.5 — 1.010 1.002 0.952 0.932
5 1.000 1.010 1.002 0.952 0.932
0 1.000 1.010 1.002 0.952 0.932
Indoor unit is lower than
outdoor unit *2
-5 0.995 1.005 0.997 0.947 0.927
-7.5 — 1.002 0.994 0.945 0.925
-10 — — 0.992 0.942 0.923
-15 — — — 0.933 0.913
6-3. Model: AOYG14KHCAN
NOTE:
Values mentioned in the table are calculated based on the maximum capacity.
COOLING
Pipe length (m)
5 7.5 10 15 20
Height difference H (m)
Indoor unit is higher than
outdoor unit *1
15 — — — 0.866 0.869
10 — — 0.926 0.867 0.876
7.5 — 0.959 0.929 0.871 0.880
5 0.992 0.963 0.933 0.874 0.883
0 1.000 0.970 0.941 0.881 0.890
Indoor unit is lower than
outdoor unit *2
-5 1.000 0.970 0.941 0.881 0.890
-7.5 — 0.970 0.941 0.881 0.890
-10 — — 0.941 0.881 0.890
-15 — — — 0.881 0.890
HEATING
Pipe length (m)
5 7.5 10 15 20
Height difference H (m)
Indoor unit is higher than
outdoor unit *1
15 — — — 0.956 0.938
10 — — 1.004 0.956 0.938
7.5 — 1.013 1.004 0.956 0.938
5 1.000 1.013 1.004 0.956 0.938
0 1.000 1.013 1.004 0.956 0.938
Indoor unit is lower than
outdoor unit *2
-5 0.995 1.008 0.999 0.951 0.933
-7.5 — 1.005 0.997 0.948 0.931
-10 — — 0.994 0.946 0.929
-15 — — — 0.937 0.919
- 42 -
6-2. Model: AOYG12KHCAN 6. Capacity compensation rate for pipe length and height difference
