5. Fan performance
5-1. Air velocity distributions
¢
Models: ASYG09KHCA and ASYG12KHCA
Measuring conditions
Fan speed Operation mode
HIGH FAN
Top view
Vertical airflow direction louver: Up
Horizontal airflow direction louver: Center
2
1
0
1
2
Unit: m/s(m)
(m)
0 1 2 3 4 5 6 7
8
9
2.0
1.0
0.5
Top view
Vertical airflow direction louver: Up
Horizontal airflow direction louver: Left & Right
3
2
1
0
1
2
3
Unit: m/s
(m)
(m)
0 1 2 3 4 5 6 7 8
9
2.0
2.0
1.0
1.0
0.5
0.5
Side view
Vertical airflow direction louver: Up
Horizontal airflow direction louver: Center
2.0
0.5
1.0
3
2
1
0
Unit: m/s
(m)
(m)
0 1 2 3 4 5 6 7 8
9
Side view
Vertical airflow direction louver: Down
Horizontal airflow direction louver: Center
2.0
0.5
1.0
3
2
1
0
Unit: m/s
(m)
(m)
0 1 2 3 4 5 6 7 8
9
