Fujitsu AOYG09KHCAN Design & Technical Manual

4-2. Heating capacity
¢
Model: ASYG09KHCA
AFR
m
3
/h
830
Indoor temperature
16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-25 -26 3.31 1.60 3.23 1.62 3.15 1.65 3.07 1.72 2.99 1.75
-20 -21 3.55 1.74 3.45 1.77 3.38 1.80 3.30 1.87 3.21 1.91
-15 -16 4.29 1.90 4.19 1.93 4.09 1.97 3.98 2.05 3.88 2.09
-10 -11 5.35 1.94 5.23 1.97 5.10 2.02 4.97 2.09 4.85 2.14
-5 -7 5.98 1.96 5.84 2.00 5.70 2.04 5.56 2.12 5.41 2.16
0 -2 6.39 2.00 6.25 2.04 6.09 2.08 5.94 2.17 5.78 2.20
5 3 7.20 2.09 7.03 2.13 6.86 2.17 6.68 2.26 6.52 2.30
7 6 7.55 2.11 7.38 2.16 7.20 2.21 7.02 2.30 6.84 2.34
10 8 7.95 1.99 7.76 2.04 7.57 2.07 7.38 2.15 7.19 2.20
15 10 8.13 1.79 7.94 1.84 7.74 1.87 7.55 1.95 7.36 1.98
20 15 8.39 1.61 8.19 1.64 7.99 1.67 7.80 1.74 7.59 1.77
24 18 7.62 1.45 7.44 1.49 7.26 1.51 7.08 1.58 6.90 1.61
¢
Model: ASYG12KHCA
AFR
m
3
/h
830
Indoor temperature
16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-25 -26 3.41 1.62 3.32 1.65 3.24 1.68 3.08 1.75 3.00 1.78
-20 -21 3.65 1.77 3.56 1.80 3.48 1.83 3.30 1.90 3.22 1.95
-15 -16 4.41 1.93 4.30 1.97 4.20 2.00 3.99 2.08 3.88 2.13
-10 -11 5.50 1.97 5.37 2.01 5.24 2.05 4.99 2.13 4.85 2.17
-5 -7 6.15 1.99 6.00 2.03 5.86 2.07 5.56 2.16 5.41 2.19
0 -2 6.58 2.03 6.42 2.07 6.26 2.11 5.95 2.19 5.79 2.24
5 3 7.40 2.11 7.23 2.16 7.05 2.20 6.70 2.29 6.52 2.34
7 6 7.77 2.15 7.58 2.18 7.40 2.24 7.03 2.33 6.84 2.38
10 8 8.16 2.01 7.97 2.05 7.78 2.10 7.39 2.18 7.19 2.22
15 10 8.36 1.82 8.16 1.87 7.96 1.90 7.56 1.98 7.37 2.01
20 15 8.63 1.63 8.42 1.67 8.21 1.70 7.80 1.77 7.60 1.80
24 18 7.83 1.48 7.64 1.51 7.46 1.53 7.08 1.60 6.90 1.62
¢
Model: ASYG14KHCA
AFR
m
3
/h
900
Indoor temperature
16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-25 -26 4.67 2.06 4.56 2.10 4.45 2.14 4.22 2.23 4.11 2.27
-20 -21 5.18 2.32 5.06 2.36 4.93 2.40 4.69 2.50 4.57 2.54
-15 -16 6.17 2.51 6.03 2.56 5.88 2.60 5.59 2.72 5.44 2.77
-10 -11 6.72 2.45 6.57 2.49 6.41 2.53 6.09 2.64 5.93 2.69
-5 -7 7.29 2.38 7.11 2.42 6.93 2.47 6.59 2.56 6.42 2.62
0 -2 7.83 2.32 7.65 2.36 7.46 2.40 7.08 2.50 6.90 2.55
5 3 8.39 2.24 8.19 2.28 7.99 2.34 7.59 2.43 7.39 2.48
7 6 8.61 2.21 8.40 2.26 8.20 2.31 7.79 2.40 7.58 2.44
10 8 9.05 2.08 8.83 2.12 8.62 2.16 8.19 2.25 7.98 2.29
15 10 9.26 1.88 9.04 1.92 8.82 1.96 8.38 2.03 8.15 2.07
20 15 9.56 1.67 9.33 1.72 9.10 1.75 8.65 1.81 8.42 1.86
24 18 8.68 1.51 8.47 1.54 8.27 1.58 7.86 1.64 7.65 1.68
- 9 -
4-2. Heating capacity 4. Capacity table
WALL MOUNTED ASYG09-14KHCA WALL MOUNTED ASYG09-14KHCA

Fujitsu AOYG09KHCAN Specifications

General

Brand	Fujitsu
Model	AOYG09KHCAN
Category	Air Conditioner
Language	English
