SPECIFICATIONS
INDOOR UNIT
OUTDOOR UNIT
Capacity
Capacity
POWER SUPPLY
Operating current
Operating current
Max operating current
Max operating current
Power consumption
Power consumption
EER
COP
Heating Cooling
Dehumidification
ASYG09KMTA
AOYG09KMTA
ASYG07KMTA
AOYG07KMTA
2.50 kW
2.80 kW
2.00 kW
2.50 kW
230 V 50 Hz Single phase
3.4 A
3.4 A
6.5 A 6.5 A
9.0 A 9.0 A
0.63 kW
0.62 kW
3.97 kW/kW
4.52 kW/kW
1.3 L/h
2.6 A
3.0 A
0.450 kW
0.555 kW
4.43 kW/kW
4.52 kW/kW
1.0 L/h
650 m
3
/h
540 m
3
/h
430 m
3
/h
270 m
3
/h
720 m
3
/h
580 m
3
/h
460 m
3
/h
330 m
3
/h
1,650 m
3
/h
1,450 m
3
/h
700 m
3
/h
560 m
3
/h
430 m
3
/h
270 m
3
/h
750 m
3
/h
610 m
3
/h
470 m
3
/h
330 m
3
/h
1,650 m
3
/h
1,450 m
3
/h
FAN MOTOR AND FAN REVOLUTION
OUTDOOR UNIT’S Discrimination
MFE-W25VA2F
INDOOR UNIT’S Discrimination
MFD-Z30YB3N
High
INDOOR UNIT
Cooling
Medium
Low
Quiet
High
INDOOR UNIT
Heating
Medium
Low
Quiet
High
Medium
Low
Quiet
1,050 rpm
900 rpm
760 rpm
550 rpm
1,140 rpm
950 rpm
800 rpm
630 rpm
930 rpm
950 rpm
1,110 rpm
920 rpm
760 rpm
550 rpm
1,180 rpm
970 rpm
810 rpm
630 rpm
930 rpm
950 rpm
ELECTRICAL DATA
INDOOR UNIT
Cooling
INDOOR UNIT
Heating
OUTDOOR
UNIT
Heating
AIRFLOW
High
Medium
Low
Quiet
Cooling
OUTDOOR
UNIT
Heating
Cooling
High
Medium
Low
Quiet
INDOOR UNIT
Cooling
INDOOR UNIT
Heating
OUTDOOR
UNIT
Heating
NOISE LEVEL
38 dB
33 dB
29 dB
High
Medium
Low
41 dB
35 dB
31 dB
22 dB
Quiet
20 dB
46 dB
Cooling
46 dB
40 dB
34 dB
29 dB
42 dB
36 dB
31 dB
22 dB
20 dB
46 dB
46 dB
2018.03.26 1
COMPRESSOR TYPE
Hermetic rotary DC
inverter compressor,
DC brushlss motor, 6 poles
DISCRIMINATION KSK66D43UERA
PRECHARGED REFRIGERANT
REFRIGERANT TYPE R32
600 g
600 g
WEIGHT (with oil)
5.96 kg
COMPRESSOR AND REFRIGERANT
Pipe length
15 m
FULL CHARGE
20 m 700 g
MAX PIPING HEIGHT DIFFERENCE
15 m
ADDITIONAL CHARGE
20 g/m
WEIGHT
INDOOR UNIT Net / Shipping
Net / Shipping
10 kg / 12.5 kg
OUTDOOR UNIT 23 kg / 26 kg
INDOOR UNIT H x W x D
H x W x D
270 x 834 x 222 mm
OUTDOOR UNIT 541 x 663 x 290 mm
DIMENSIONS

Fujitsu AOYG09KMTA Specifications

General

Type	Air conditioner outdoor unit
Ionizer	-
Multi-split	No
Product color	White
Compressor type	Rotary
Gas hose diameter	9.5 mm
Hose length (max)	15 m
Inverter technology	Yes
Liquid hose diameter	6.35 mm
Refrigerating medium	R32
Air conditioner functions	Cooling, Heating
Refrigerating medium weight	600 g
Cooling capacity in watts (nominal)	- W
Operating temperature (cooling) (T-T)	-10 - 46 °C
Operating temperature (heating) (T-T)	-15 - 24 °C
AC input voltage	230 V
AC input frequency	50 Hz
Design load (cooling)	- kW
Hourly energy consumption (cooling)	- kWh
Indoor unit noise level (high speed)	- dB
Outdoor unit depth	290 mm
Outdoor unit width	663 mm
Outdoor unit height	541 mm
Outdoor unit weight	23000 g
Outdoor units quantity	1
Outdoor unit noise level	61 dB
Cooling airflow (outdoor unit)	750 m³/h
Outdoor unit sound power level	46 dB
