3-1. FUNCTION SETTING
3-1-1 INDOOR UNIT
Remote controller address setting
Filter sign
* Because this setting is normally done automatically when 2-wire-type wired remote controller
is installed, setting is unnecessary.
Multiple indoor units can be operated by using one wired remote controller.
Set the unit number of each indoor unit.
*When connecting Polar 3-core wired remote controller, set the remote controller address
in the order of 0, 1, 2, ......, and 15.
Select appropriate intervals for displaying the filter sign on the indoor unit according to the
estimated amount of dust in the air of the room.
If the indication is not required, select “No indication” (03).
*When cdifferent type of indoor units (such as wall-mounted type and cassette type, cassette
type and duct type, or other combinations) are connected using group control system, some
functions may no longer be available.
Setting Description
Function Number Setting Value
Standard (400 hours)
Long interval (1,000 hours)
Short interval (200 hours)
No indication
11
00
01
02
03
Unit no.0
Unit no.1
Unit no.2
Unit no.3
Unit no.4
Unit no.5
Unit no.6
Unit no.7
Unit no.8
Unit no.9
Unit no.10
Unit no.11
Unit no.12
Unit no.13
Unit no.14
Unit no.15
14
13
12
11
10
09
08
07
06
05
04
03
02
01
00
setting Description
15
00
Setting Value
Function
Number
Factory
setting
Factory setting

Fujitsu AOYG09KMTA Specifications

General

Type	Air conditioner outdoor unit
Ionizer	-
Multi-split	No
Product color	White
Compressor type	Rotary
Gas hose diameter	9.5 mm
Hose length (max)	15 m
Inverter technology	Yes
Liquid hose diameter	6.35 mm
Refrigerating medium	R32
Air conditioner functions	Cooling, Heating
Refrigerating medium weight	600 g
Cooling capacity in watts (nominal)	- W
Operating temperature (cooling) (T-T)	-10 - 46 °C
Operating temperature (heating) (T-T)	-15 - 24 °C
AC input voltage	230 V
AC input frequency	50 Hz
Design load (cooling)	- kW
Hourly energy consumption (cooling)	- kWh
Indoor unit noise level (high speed)	- dB
Outdoor unit depth	290 mm
Outdoor unit width	663 mm
Outdoor unit height	541 mm
Outdoor unit weight	23000 g
Outdoor units quantity	1
Outdoor unit noise level	61 dB
Cooling airflow (outdoor unit)	750 m³/h
Outdoor unit sound power level	46 dB
