Fujitsu AOYG09KMTA User Manual

22. DEFROST OPERATION CONTROL
01-17
1. CONDITION OF STARTING THE DEFROST OPERATION
The defrost operation starts when the outdoor heat exchanger temperature sensor (Tn) detects
the temperature lower than the values shown in Table22.
2. CONDITION OF THE DEFROST OPERATION COMPLETION
Defrost operation is released when the conditions become as shown in Table 23.
( Table 23 : Defrost Release Condition )
Release Condition
Outdoor heat exchanger temperature sensor value is higher than +16°C.
or Compressor operation time has passed 15 minutes.
( Table 22 : Condition of starting Defrost Operation )
1 time defrosting
after starting operation
ST
Defrosting after 2ND time
upon starting operation
Compressor integrating operation time
Compressor integrating operation time
Compressor integrating operation time
Less than 22 min. 22 to 62 min. More than 62 min.
Does not operate
- 9°C - 5°C
07-12KM: Less than 25 min.
14KM: Less than 40 min.
07-12KM: More than 25min.
14KM: More than 40min.
Integrating defrost
(Constant monitoring)
More than 240 min.
(For long continuous operation)
Less than 10min.*1
(For intermittent operation)
- 3°C
More than 215 min.
(For long continuous operation)
- 5°C
OFF count of the compressor
40 times.
*1 : If the compressor continuous operation time is less than 10 minutes,
the OFF number of the compressor is counted.
If any defrost operated, the compressor OFF count is cleared.
Tn10 : Temperature of continuous operation at 10minutes.
Tnb : Back 5minutes temperature
Does not operate
Outdoor heat exchanger temp. < -17°C
(at outside air temp. > -10°C)
(at outside air temp. < -10°C)
1 Outdoor heat exchanger temp.< -20°C
2 Outdoor heat exchanger temp.< Outside air temp.
3 Tn-Tn10< -5°C (and Tn< -6°C)
4 Tn-Tnb< -2°C (and Tn< -6°C)
=
=

Fujitsu AOYG09KMTA Specifications

General

Type	Air conditioner outdoor unit
Ionizer	-
Multi-split	No
Product color	White
Compressor type	Rotary
Gas hose diameter	9.5 mm
Hose length (max)	15 m
Inverter technology	Yes
Liquid hose diameter	6.35 mm
Refrigerating medium	R32
Air conditioner functions	Cooling, Heating
Refrigerating medium weight	600 g
Cooling capacity in watts (nominal)	- W
Operating temperature (cooling) (T-T)	-10 - 46 °C
Operating temperature (heating) (T-T)	-15 - 24 °C
AC input voltage	230 V
AC input frequency	50 Hz
Design load (cooling)	- kW
Hourly energy consumption (cooling)	- kWh
Indoor unit noise level (high speed)	- dB
Outdoor unit depth	290 mm
Outdoor unit width	663 mm
Outdoor unit height	541 mm
Outdoor unit weight	23000 g
Outdoor units quantity	1
Outdoor unit noise level	61 dB
Cooling airflow (outdoor unit)	750 m³/h
Outdoor unit sound power level	46 dB
