DUCT TYPE ARYG12-54LHTBP
3. Specifications
3-1. Models: ARYG12LHTBP and ARYG14LHTBP
Type
Duct
Inverter heat pump
Model name
ARYG12LHTBP ARYG14LHTBP
Power supply 230 V ~ 50 Hz
Available voltage range 198—264 V
Capacity
Cooling
Rated
kW 3.5 4.3
Btu/h 11,950 14,650
Min.—Max.
kW 0.9 — 4.4 0.9 — 5.4
Btu/h 3,100 — 15,000 3,100 — 18,400
Heating
Rated
kW 4.1 5.0
Btu/h 14,000 17,050
Min.—Max.
kW 0.9 — 5.7 0.9 — 6.5
Btu/h 3,100 — 19,400 3,100 - 22,100
Input power
Cooling
Rated
kW
0.90 1.18
Max. 1.71 2.08
Heating
Rated 1.00 1.25
Max. 2.33 2.97
Fan
HIGH
W
54 65
MED 29 36
LOW 21 26
QUIET 15 18
Current
Cooling
Rated A
4.2 5.4
Heating 4.7 5.7
Power factor
Cooling
%
93.2 95.0
Heating 92.5 95.3
EER Cooling
kW/kW
3.89 3.64
COP Heating 4.10 4.00
Moisture removal L/h (pints/h) 0.7 (1.2) 0.9 (1.6)
Maximum operating current *1
Cooling
A
8.0 9.5
Heating 10.5 13.0
Fan
Airflow rate
Cooling
HIGH
m
3
/h
850 950
MED 680 760
LOW 590 670
QUIET 510 570
Heating
HIGH 850 950
MED 680 760
LOW 590 670
QUIET 510 570
Type × Q'ty Sirocco fan × 1
Motor output W 154
Static pressure range Pa 30 to 200
Sound pressure level *2
Cooling
HIGH
dB (A)
32 33
MED 27 28
LOW 26 27
QUIET 24 25
Heating
HIGH 32 33
MED 27 28
LOW 26 27
QUIET 24 25
Sound power level
Cooling
dB (A)
57 59
Heating 58 60
Heat exchanger type
Dimensions (H × W × D)
mm
420 × 458 × 39.9
Fin pitch 1.4
Rows × Stages 3 × 20
Pipe type Copper
Fin type
Aluminum
Hydrophilic coating
Enclosure
Material Steel
Color ―
Dimensions
(H × W × D)
Net
mm
300 × 700 × 700
Gross 400 × 938 × 875
Weight
Net
kg
27
Gross 34
Connection pipe
Size
Liquid
mm (in)
Ø 6.35 (Ø 1/4) Ø 6.35 (Ø 1/4)
Gas Ø 9.52 (Ø 3/8) Ø 12.7 (Ø 1/2)
Method Flare
Drain hose
Material PVC
Size mm Ø 25 (I.D.), Ø 32 (O.D.) (VP25)
Operation range
Cooling
°C 18 to 32
%RH 80 or less
Heating °C 16 to 30

Fujitsu AOYG18LBCA Specifications
