DUCT TYPE ARYG12-54LHTBP
3-2. Models: ARYG18LHTBP, ARYG24LHTBP, and
ARYG30LHTBP
Type
Duct
Inverter heat pump
Model name
ARYG18LHTBP ARYG24LHTBP ARYG30LHTBP
Power supply 230 V ~ 50 Hz
Available voltage range 198—264 V
Capacity
Cooling
Rated
kW 5.2 6.8 8.5
Btu/h 17,700 23,200 29,000
Min.—Max.
kW 0.9 — 6.5 0.9 — 8.0 2.8—10.0
Btu/h 3,100 — 22,200 3,100 — 27,300 9,500 - 34,100
Heating
Rated
kW 6.0 8.0 10.0
Btu/h 20,500 27,300 34,100
Min.—Max.
kW 0.9 — 8.0 0.9 — 9.1 2.7—11.2
Btu/h 3,100 — 27,300 3,100 - 31,000 9,200 - 38,200
Input power
Cooling
Rated
kW
1.37 1.95 2.65
Max. 2.25 3.19 4.05
Heating
Rated 1.48 2.21 2.70
Max. 3.16 4.40 4.06
Fan
HIGH
W
50 70 150
MED 30 40 100
LOW 202575
QUIET 15 15 65
Current
Cooling
Rated A
6.1 8.6 11.6
Heating 6.6 9.7 11.8
Power factor
Cooling
%
97.6 98.6 99.3
Heating 97.5 99.1 99.5
EER Cooling
kW/kW
3.80 3.49 3.21
COP Heating 4.05 3.62 3.70
Moisture removal L/h (pints/h) 1.2 (2.1) 1.8 (3.2) 2.3 (4.0)
Maximum operating current *1
Cooling
A
10.0 13.5 17.0
Heating 13.5 18.5 17.0
Fan
Airflow rate
Cooling
HIGH
m
3
/h
1,050 1,360 1,700
MED 840 1,080 1,360
LOW 740 880 1,190
QUIET 630 680 1,070
Heating
HIGH 1,050 1,360 1,700
MED 840 1,080 1,360
LOW 740 880 1,190
QUIET 630 680 1,070
Type × Q'ty Sirocco fan × 2
Motor output W 197 375
Static pressure range Pa 30 to 200
Sound pressure level *2
Cooling
HIGH
dB (A)
28 32 36
MED 252833
LOW 222430
QUIET 20 21 29
Heating
HIGH 28 32 36
MED 252833
LOW 222430
QUIET 20 21 29
Sound power level
Cooling
dB (A)
54 57 63
Heating 545765
Heat exchanger type
Dimensions (H × W × D)
mm
420 × 758 × 39.9
Fin pitch 1.4
Rows × Stages 3 × 20
Pipe type Copper
Fin type
Aluminum
Hydrophilic coating
Enclosure
Material Steel
Color ―
Dimensions
(H × W × D)
Net
mm
300 × 1,000 × 700
Gross 400 × 1,238 × 875
Weight
Net
kg
36
Gross 43 44
Connection pipe
Size
Liquid
mm (in)
Ø 6.35 (Ø 1/4) Ø 6.35 (Ø 1/4) Ø 9.52 (Ø 3/8)
Gas Ø 12.7 (Ø 1/2) Ø 15.88 (Ø 5/8) Ø 15.88 (Ø 5/8)
Method Flare
Drain hose
Material PVC
Size mm Ø 25 (I.D.), Ø 32 (O.D.) (VP25)
Operation range
Cooling
°C 18 to 32
%RH 80 or less
Heating °C 16 to 30
