OUTDOOR UNIT AOYG12-54LB
1-2. Models: AOYG18LBCA and AOYG24LBCA
Type
Inverter heat pump
Model name
AOYG18LBCA AOYG24LBCA
Power supply 230 V ~ 50 Hz
Available voltage range 198—264 V
Starting current A6.69.7
Fan
Airflow rate
Cooling
m
3
/h
1,900 2,460
Heating 1,700 2,340
Type × Q'ty Propeller × 1
Motor output W 49
Sound pressure level *1
Cooling
dB (A)
50 55
Heating 51 56
Sound power level
Cooling
dB (A)
63 68
Heating 62 68
Heat exchanger type
Dimensions (H × W × D)
mm
Main:588 × 881 × 36.4
Sub:546 × 580 × 18.2
Fin pitch 1.45
Rows × Stages Main:2 × 28 Sub:1 × 26
Pipe type Copper
Fin
Type (Material) Corrugate (Aluminum)
Surface treatment Hydrophilic coating (Blue fin)
Compressor
Type × Q'ty Twin rotary × 1
Motor output W 1,100
Refrigerant
Type R410A
Factory charge g 1,800
Refrigerant oil
Type POE (RB68)
Amount
cm
3
600
Enclosure
Material Steel
Color
Beige
Approximate color of MUNSELL 10YR7.5/1.0
Dimensions
(H × W × D)
Net
mm
620 × 790 × 290
Gross 713 × 945 × 395
Weight
Net
kg
41
Gross 45
Connection pipe
Size
Liquid
mm (in)
Ø 6.35 (Ø 1/4) Ø 6.35 (Ø 1/4)
Gas Ø 12.7 (Ø 1/2) Ø 15.88 (Ø 5/8)
Method Flare
Pre-charge length
m
15
Max. length 30
Max. height difference 20
Operation range
Cooling
°C
-15 to 46
Heating -15 to 24
NOTES:
Specifications are based on the following conditions:
–Cooling: Indoor temperature of 27 °CDB/19 °CWB, and outdoor temperature of 35 °CDB/24 °CWB.
–Heating: Indoor temperature of 20 °CDB/15 °CWB, and outdoor temperature of 7 °CDB/6 °CWB.
–Pipe length: 5 m, Height difference: 0 m.
Protective function might work when using it outside the operation range.
*1: Sound pressure level
–Measured values in manufacturer’s anechoic chamber.
–Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
