15-4. Wall mounted type

Models: ASYG07LUCA, ASYG09LUCA, ASYG12LUCA, and

ASYG14LUCA

Part name Exterior Q’ty Part name Exterior Q’ty

Operating manual 1 Cloth tape 1

Installation manual 1

Tapping screw (large),

M4 × 25 mm

Wall hook bracket 1

Tapping screw (small),

M3 × 12 mm

Remote controller 1 Air cleaning filter 2

Battery 2

Seal A

• It is necessary when

using AS14.

• It is used when the

diameter of gas pipe

is Ø12.70 or more.

Remote controller

holder

DESIGN & TECHNICAL MANUAL

- 258 -

MULTI TYPE

5, 6 ROOMS TYPE
