2-5. Floor/Ceiling type
Model name ABYG14LVTA ABYG18LVTB
Power supply 1Ø 230 V ~50 Hz
Available voltage range 198—264 V
Capacity kWh class 4.0 5.0
Input power W 26 47
Running current A 0.21 0.36
Fan
Airflow rate
Cooling
HIGH
m
3
/h
640 780
MED 590 700
LOW 540 560
QUIET 480 500
Heating
HIGH 640 780
MED 590 700
LOW 540 560
QUIET 480 500
Type × Q'ty Sirocco fan × 2
Motor output W 80
Sound pressure level *
Cooling
HIGH
dB (A)
36 (Under ceiling)
39 (Floor console)
41 (Under ceiling)
44 (Floor console)
MED
34 (Under ceiling)
37 (Floor console)
38 (Under ceiling)
41 (Floor console)
LOW
33 (Under ceiling)
36 (Floor console)
34 (Under ceiling)
37 (Floor console)
QUIET
29 (Under ceiling)
32 (Floor console)
32 (Under ceiling)
35 (Floor console)
Heating
HIGH
36 (Under ceiling)
39 (Floor console)
41 (Under ceiling)
44 (Floor console)
MED
34 (Under ceiling)
37 (Floor console)
38 (Under ceiling)
41 (Floor console)
LOW
33 (Under ceiling)
36 (Floor console)
34 (Under ceiling)
37 (Floor console)
QUIET
29 (Under ceiling)
32 (Floor console)
32 (Under ceiling)
35 (Floor console)
Sound power level
Cooling
dB (A)
51 55
Heating 51 55
Heat exchanger type
Dimensions (H × W × D) mm 252 × 800 × 26.6 252 × 800 × 39.9
Fin pitch mm 1.2 1.3
Rows × Stages 2 × 12 3 × 12
Pipe type Copper tube
Fin type Aluminum
Enclosure
Material ABS
Color
White
(Approximate color of Munsell N 9.25/)
Dimensions
(H × W × D)
Net
mm
199 × 990 × 655
Gross 320 × 1,150 × 790
Weight
Net
kg
27
Gross 36
Connection
pipe
Size
Liquid
mm (in)
Ø6.35 (Ø1/4)
Gas Ø12.70 (Ø1/2)
Method Flare
Drain hose
Material Hard PVC
Size mm Ø25 (I.D.), Ø32 (O.D.)
Operation range
Cooling
°C 18 to 32
%RH 80 or less
Heating °C 16 to 30
Remote controller type Wireless (Wired [option])
NOTES:
• The protective function might work when using it outside the operation range.
• *Sound pressure level:
– Measured values in manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
- 19 -
MULTI TYPE 5, 6 ROOMS TYPE

Fujitsu AOYG36LBLA5 Specifications

General

Type	Air conditioner outdoor unit
Multi-split	No
Product color	White
Compressor type	Rotary
Gas hose diameter	9.52 mm
Hose length (max)	80 m
Hose length (min)	25 m
Inverter technology	-
Liquid hose diameter	6.35 mm
Refrigerating medium	R410A
Air conditioner functions	Cooling, Heating
Cooling capacity in watts (max)	12500 W
Heating capacity in watts (max)	14000 W
Heating capacity in watts (min)	3500 W
Cooling capacity in watts (nominal)	- W
Operating temperature (cooling) (T-T)	-10 - 46 °C
Operating temperature (heating) (T-T)	-15 - 24 °C
AC input voltage	230 V
AC input frequency	50 Hz
Design load (cooling)	- kW
Hourly energy consumption (cooling)	- kWh
Indoor unit noise level (high speed)	- dB
Outdoor unit depth	370 mm
Outdoor unit width	970 mm
Outdoor unit height	998 mm
Outdoor unit weight	94000 g
Outdoor units quantity	1
Outdoor unit noise level	67 dB
Outdoor unit sound power level	68 dB
