Fujitsu AOYG36LBLA5 User Manual

Indoor unit connect-
ing capacity
Outdoor temperature
Indoor temperature
18.0 °CDB 21.0 °CDB 23.0 °CDB 27.0 °CDB 29.0 °CDB 32.0 °CDB
12.0 °CWB 15.0 °CWB 16.0 °CWB 19.0 °CWB 21.0 °CWB 23.0 °CWB
kBtu/h °CDB TC IP TC IP TC IP TC IP TC IP TC IP
48
-10.0
9.80 1.42 11.08 1.45 11.68 1.46 12.50 1.48 13.36 1.49 13.78 1.50
-5.0 9.80 1.42 11.08 1.44 11.68 1.45 12.50 1.47 13.36 1.49 13.78 1.49
0.0 9.80 1.41 11.08 1.43 11.68 1.45 12.50 1.46 13.36 1.48 13.78 1.49
5.0 9.80 1.57 11.08 1.60 11.68 1.61 12.50 1.63 13.36 1.65 13.78 1.66
10.0 9.80 1.73 11.08 1.76 11.68 1.78 12.50 1.80 13.36 1.82 13.78 1.83
15.0 9.80 2.38 11.08 2.42 11.68 2.44 12.50 2.47 13.36 2.50 13.78 2.51
20.0 9.80 3.03 11.08 3.09 11.68 3.11 12.50 3.15 13.36 3.18 13.78 3.20
25.0 9.80 3.34 11.08 3.40 11.68 3.43 12.50 3.47 13.36 3.51 13.78 3.53
30.0 9.80 3.65 11.08 3.72 11.68 3.75 12.50 3.79 13.36 3.83 13.78 3.85
35.0 9.80 3.90 11.08 3.97 11.68 4.00 12.50 4.04 13.36 4.09 13.78 4.11
40.0 9.27 4.09 10.48 4.17 11.05 4.20 11.83 4.25 12.64 4.30 13.03 4.32
46.0 8.75 4.29 9.88 4.36 10.42 4.40 11.15 4.45 11.92 4.50 12.29 4.52
47
-10.0
9.80 1.42 11.08 1.45 11.68 1.46 12.50 1.48 13.36 1.49 13.78 1.50
-5.0 9.80 1.42 11.08 1.44 11.68 1.45 12.50 1.47 13.36 1.49 13.78 1.49
0.0 9.80 1.41 11.08 1.43 11.68 1.45 12.50 1.46 13.36 1.48 13.78 1.49
5.0 9.80 1.57 11.08 1.60 11.68 1.61 12.50 1.63 13.36 1.65 13.78 1.66
10.0 9.80 1.73 11.08 1.76 11.68 1.78 12.50 1.80 13.36 1.82 13.78 1.83
15.0 9.80 2.38 11.08 2.42 11.68 2.44 12.50 2.47 13.36 2.50 13.78 2.51
20.0 9.80 3.03 11.08 3.09 11.68 3.11 12.50 3.15 13.36 3.18 13.78 3.20
25.0 9.80 3.34 11.08 3.40 11.68 3.43 12.50 3.47 13.36 3.51 13.78 3.53
30.0 9.80 3.65 11.08 3.72 11.68 3.75 12.50 3.79 13.36 3.83 13.78 3.85
35.0 9.80 3.90 11.08 3.97 11.68 4.00 12.50 4.04 13.36 4.09 13.78 4.11
40.0 9.27 4.09 10.48 4.17 11.05 4.20 11.83 4.25 12.64 4.30 13.03 4.32
46.0 8.75 4.29 9.88 4.36 10.42 4.40 11.15 4.45 11.92 4.50 12.29 4.52
46
-10.0
9.80 1.42 11.08 1.45 11.68 1.46 12.50 1.48 13.36 1.49 13.78 1.50
-5.0 9.80 1.42 11.08 1.44 11.68 1.45 12.50 1.47 13.36 1.49 13.78 1.49
0.0 9.80 1.41 11.08 1.43 11.68 1.45 12.50 1.46 13.36 1.48 13.78 1.49
5.0 9.80 1.57 11.08 1.60 11.68 1.61 12.50 1.63 13.36 1.65 13.78 1.66
10.0 9.80 1.73 11.08 1.76 11.68 1.78 12.50 1.80 13.36 1.82 13.78 1.83
15.0 9.80 2.38 11.08 2.42 11.68 2.44 12.50 2.47 13.36 2.50 13.78 2.51
20.0 9.80 3.03 11.08 3.09 11.68 3.11 12.50 3.15 13.36 3.18 13.78 3.20
25.0 9.80 3.34 11.08 3.40 11.68 3.43 12.50 3.47 13.36 3.51 13.78 3.53
30.0 9.80 3.65 11.08 3.72 11.68 3.75 12.50 3.79 13.36 3.83 13.78 3.85
35.0 9.80 3.90 11.08 3.97 11.68 4.00 12.50 4.04 13.36 4.09 13.78 4.11
40.0 9.27 4.09 10.48 4.17 11.05 4.20 11.83 4.25 12.64 4.30 13.03 4.32
46.0 8.75 4.29 9.88 4.36 10.42 4.40 11.15 4.45 11.92 4.50 12.29 4.52
45
-10.0
9.80 1.42 11.08 1.45 11.68 1.46 12.50 1.48 13.36 1.49 13.78 1.50
-5.0 9.80 1.42 11.08 1.44 11.68 1.45 12.50 1.47 13.36 1.49 13.78 1.49
0.0 9.80 1.41 11.08 1.43 11.68 1.45 12.50 1.46 13.36 1.48 13.78 1.49
5.0 9.80 1.57 11.08 1.60 11.68 1.61 12.50 1.63 13.36 1.65 13.78 1.66
10.0 9.80 1.73 11.08 1.76 11.68 1.78 12.50 1.80 13.36 1.82 13.78 1.83
15.0 9.80 2.38 11.08 2.42 11.68 2.44 12.50 2.47 13.36 2.50 13.78 2.51
20.0 9.80 3.03 11.08 3.09 11.68 3.11 12.50 3.15 13.36 3.18 13.78 3.20
25.0 9.80 3.34 11.08 3.40 11.68 3.43 12.50 3.47 13.36 3.51 13.78 3.53
30.0 9.80 3.65 11.08 3.72 11.68 3.75 12.50 3.79 13.36 3.83 13.78 3.85
35.0 9.80 3.90 11.08 3.97 11.68 4.00 12.50 4.04 13.36 4.09 13.78 4.11
40.0 9.27 4.09 10.48 4.17 11.05 4.20 11.83 4.25 12.64 4.30 13.03 4.32
46.0 8.75 4.29 9.88 4.36 10.42 4.40 11.15 4.45 11.92 4.50 12.29 4.52
44
-10.0
9.80 1.42 11.08 1.45 11.68 1.46 12.50 1.48 13.36 1.49 13.78 1.50
-5.0 9.80 1.42 11.08 1.44 11.68 1.45 12.50 1.47 13.36 1.49 13.78 1.49
0.0 9.80 1.41 11.08 1.43 11.68 1.45 12.50 1.46 13.36 1.48 13.78 1.49
5.0 9.80 1.57 11.08 1.60 11.68 1.61 12.50 1.63 13.36 1.65 13.78 1.66
10.0 9.80 1.73 11.08 1.76 11.68 1.78 12.50 1.80 13.36 1.82 13.78 1.83
15.0 9.80 2.38 11.08 2.42 11.68 2.44 12.50 2.47 13.36 2.50 13.78 2.51
20.0 9.80 3.03 11.08 3.09 11.68 3.11 12.50 3.15 13.36 3.18 13.78 3.20
25.0 9.80 3.34 11.08 3.40 11.68 3.43 12.50 3.47 13.36 3.51 13.78 3.53
30.0 9.80 3.65 11.08 3.72 11.68 3.75 12.50 3.79 13.36 3.83 13.78 3.85
35.0 9.80 3.90 11.08 3.97 11.68 4.00 12.50 4.04 13.36 4.09 13.78 4.11
40.0 9.27 4.09 10.48 4.17 11.05 4.20 11.83 4.25 12.64 4.30 13.03 4.32
46.0 8.75 4.29 9.88 4.36 10.42 4.40 11.15 4.45 11.92 4.50 12.29 4.52
43
-10.0
9.80 1.42 11.08 1.45 11.68 1.46 12.50 1.48 13.36 1.49 13.78 1.50
-5.0 9.80 1.42 11.08 1.44 11.68 1.45 12.50 1.47 13.36 1.49 13.78 1.49
0.0 9.80 1.41 11.08 1.43 11.68 1.45 12.50 1.46 13.36 1.48 13.78 1.49
5.0 9.80 1.57 11.08 1.60 11.68 1.61 12.50 1.63 13.36 1.65 13.78 1.66
10.0 9.80 1.73 11.08 1.76 11.68 1.78 12.50 1.80 13.36 1.82 13.78 1.83
15.0 9.80 2.38 11.08 2.42 11.68 2.44 12.50 2.47 13.36 2.50 13.78 2.51
20.0 9.80 3.03 11.08 3.09 11.68 3.11 12.50 3.15 13.36 3.18 13.78 3.20
25.0 9.80 3.34 11.08 3.40 11.68 3.43 12.50 3.47 13.36 3.51 13.78 3.53
30.0 9.80 3.65 11.08 3.72 11.68 3.75 12.50 3.79 13.36 3.83 13.78 3.85
35.0 9.80 3.90 11.08 3.97 11.68 4.00 12.50 4.04 13.36 4.09 13.78 4.11
40.0 9.27 4.09 10.48 4.17 11.05 4.20 11.83 4.25 12.64 4.30 13.03 4.32
46.0 8.75 4.29 9.88 4.36 10.42 4.40 11.15 4.45 11.92 4.50 12.29 4.52
42
-10.0
9.80 1.42 11.08 1.45 11.68 1.46 12.50 1.48 13.36 1.49 13.78 1.50
-5.0 9.80 1.42 11.08 1.44 11.68 1.45 12.50 1.47 13.36 1.49 13.78 1.49
0.0 9.80 1.41 11.08 1.43 11.68 1.45 12.50 1.46 13.36 1.48 13.78 1.49
5.0 9.80 1.57 11.08 1.60 11.68 1.61 12.50 1.63 13.36 1.65 13.78 1.66
10.0 9.80 1.73 11.08 1.76 11.68 1.78 12.50 1.80 13.36 1.82 13.78 1.83
15.0 9.80 2.38 11.08 2.42 11.68 2.44 12.50 2.47 13.36 2.50 13.78 2.51
20.0 9.80 3.03 11.08 3.09 11.68 3.11 12.50 3.15 13.36 3.18 13.78 3.20
25.0 9.80 3.34 11.08 3.40 11.68 3.43 12.50 3.47 13.36 3.51 13.78 3.53
30.0 9.80 3.65 11.08 3.72 11.68 3.75 12.50 3.79 13.36 3.83 13.78 3.85
35.0 9.80 3.90 11.08 3.97 11.68 4.00 12.50 4.04 13.36 4.09 13.78 4.11
40.0 9.27 4.09 10.48 4.17 11.05 4.20 11.83 4.25 12.64 4.30 13.03 4.32
46.0 8.75 4.29 9.88 4.36 10.42 4.40 11.15 4.45 11.92 4.50 12.29 4.52
DESIGN & TECHNICAL MANUAL
- 288 -
OUTDOOR UNIT AOYG36LBLA5

Fujitsu AOYG36LBLA5 Specifications

General

Type	Air conditioner outdoor unit
Multi-split	No
Product color	White
Compressor type	Rotary
Gas hose diameter	9.52 mm
Hose length (max)	80 m
Hose length (min)	25 m
Inverter technology	-
Liquid hose diameter	6.35 mm
Refrigerating medium	R410A
Air conditioner functions	Cooling, Heating
Cooling capacity in watts (max)	12500 W
Heating capacity in watts (max)	14000 W
Heating capacity in watts (min)	3500 W
Cooling capacity in watts (nominal)	- W
Operating temperature (cooling) (T-T)	-10 - 46 °C
Operating temperature (heating) (T-T)	-15 - 24 °C
AC input voltage	230 V
AC input frequency	50 Hz
Design load (cooling)	- kW
Hourly energy consumption (cooling)	- kWh
Indoor unit noise level (high speed)	- dB
Outdoor unit depth	370 mm
Outdoor unit width	970 mm
Outdoor unit height	998 mm
Outdoor unit weight	94000 g
Outdoor units quantity	1
Outdoor unit noise level	67 dB
Outdoor unit sound power level	68 dB
