Fujitsu AOYG36LBLA5 User Manual

Combination of indoor unit Rated capacity for each indoor unit (kBtu/h)
Total capacity
(kBtu/h)
Input power (kW)
EER
(W/W)Room
Total
Room
Min.
Rated
Max. Min.
Rated
Max.
1 2 3 4 5 6 1 2 3 4 5 6
7 7 12 14 14 — 54 1.62 1.62 2.78 3.24 3.24 — 3.5 12.5 14.0 0.8 3.60 4.84 3.47
7 7 12 14 18 — 58 1.51 1.51 2.59 3.02 3.87 — 3.5 12.5 14.0 0.8 3.57 4.84 3.50
7 7 12 18 18 — 62 1.41 1.41 2.42 3.63 3.63 — 3.5 12.5 14.0 0.8 3.55 4.84 3.52
7 7 14 14 14 — 56 1.56 1.56 3.13 3.13 3.13 — 3.5 12.5 14.0 0.8 3.59 4.84 3.48
7 7 14 14 18 — 60 1.46 1.46 2.92 2.92 3.74 — 3.5 12.5 14.0 0.8 3.56 4.84 3.51
7 9 9 9 9 — 43 2.00 2.50 2.50 2.50 2.50 — 3.5 12.0 13.7 0.8 3.47 4.65 3.46
7 9 9 9 12 — 46 1.90 2.45 2.45 2.45 3.25 — 3.5 12.5 14.0 0.8 3.65 4.84 3.42
7 9 9 9 14 — 48 1.82 2.34 2.34 2.34 3.66 — 3.5 12.5 14.0 0.8 3.64 4.84 3.43
7 9 9 9 18 — 52 1.68 2.16 2.16 2.16 4.34 — 3.5 12.5 14.0 0.8 3.61 4.84 3.46
7 9 9 9 24 — 58 1.51 1.94 1.94 1.94 5.17 — 3.5 12.5 14.0 0.8 3.57 4.84 3.50
7 9 9 12 12 — 49 1.78 2.30 2.30 3.06 3.06 — 3.5 12.5 14.0 0.8 3.63 4.84 3.44
7 9 9 12 14 — 51 1.72 2.21 2.21 2.94 3.42 — 3.5 12.5 14.0 0.8 3.62 4.84 3.45
7 9 9 12 18 — 55 1.59 2.05 2.05 2.73 4.08 — 3.5 12.5 14.0 0.8 3.59 4.84 3.48
7 9 9 12 24 — 61 1.43 1.84 1.84 2.46 4.93 — 3.5 12.5 14.0 0.8 3.56 4.84 3.51
7 9 9 14 14 — 53 1.66 2.12 2.12 3.30 3.30 — 3.5 12.5 14.0 0.8 3.60 4.84 3.47
7 9 9 14 18 — 57 1.54 1.97 1.97 3.07 3.95 — 3.5 12.5 14.0 0.8 3.58 4.84 3.49
7 9 9 18 18 — 61 1.44 1.84 1.84 3.69 3.69 — 3.5 12.5 14.0 0.8 3.56 4.84 3.51
7 9 12 12 12 — 52 1.69 2.17 2.88 2.88 2.88 — 3.5 12.5 14.0 0.8 3.61 4.84 3.46
7 9 12 12 14 — 54 1.62 2.08 2.78 2.78 3.24 — 3.5 12.5 14.0 0.8 3.60 4.84 3.47
7 9 12 12 18 — 58 1.51 1.94 2.59 2.59 3.87 — 3.5 12.5 14.0 0.8 3.57 4.84 3.50
7 9 12 14 14 — 56 1.55 2.01 2.68 3.13 3.13 — 3.5 12.5 14.0 0.8 3.59 4.84 3.48
7 9 12 14 18 — 60 1.46 1.88 2.50 2.92 3.74 — 3.5 12.5 14.0 0.8 3.56 4.84 3.51
7 9 14 14 14 — 58 1.50 1.94 3.02 3.02 3.02 — 3.5 12.5 14.0 0.8 3.57 4.84 3.50
7 9 14 14 18 — 62 1.41 1.81 2.82 2.82 3.64 — 3.5 12.5 14.0 0.8 3.55 4.84 3.52
7 12 12 12 12 — 55 1.58 2.73 2.73 2.73 2.73 — 3.5 12.5 14.0 0.8 3.59 4.84 3.48
7 12 12 12 14 — 57 1.54 2.63 2.63 2.63 3.07 — 3.5 12.5 14.0 0.8 3.58 4.84 3.49
7 12 12 12 18 — 61 1.43 2.46 2.46 2.46 3.69 — 3.5 12.5 14.0 0.8 3.56 4.84 3.51
7 12 12 14 14 — 59 1.48 2.54 2.54 2.97 2.97 — 3.5 12.5 14.0 0.8 3.57 4.84 3.50
7 12 14 14 14 — 61 1.43 2.46 2.87 2.87 2.87 — 3.5 12.5 14.0 0.8 3.56 4.84 3.51
9 9 9 9 9 — 45 2.50 2.50 2.50 2.50 2.50 — 3.5 12.5 14.0 0.8 3.65 4.84 3.42
9 9 9 9 12 — 48 2.34 2.34 2.34 2.34 3.14 — 3.5 12.5 14.0 0.8 3.64 4.84 3.43
9 9 9 9 14 — 50 2.25 2.25 2.25 2.25 3.50 — 3.5 12.5 14.0 0.8 3.62 4.84 3.45
9 9 9 9 18 — 54 2.08 2.08 2.08 2.08 4.18 — 3.5 12.5 14.0 0.8 3.60 4.84 3.47
9 9 9 9 24 — 60 1.88 1.88 1.88 1.88 4.98 — 3.5 12.5 14.0 0.8 3.56 4.84 3.51
9 9 9 12 12 — 51 2.21 2.21 2.21 2.94 2.94 — 3.5 12.5 14.0 0.8 3.62 4.84 3.45
9 9 9 12 14 — 53 2.12 2.12 2.12 2.83 3.31 — 3.5 12.5 14.0 0.8 3.60 4.84 3.47
9 9 9 12 18 — 57 1.97 1.97 1.97 2.63 3.96 — 3.5 12.5 14.0 0.8 3.58 4.84 3.49
9 9 9 14 14 — 55 2.05 2.05 2.05 3.18 3.18 — 3.5 12.5 14.0 0.8 3.59 4.84 3.48
9 9 9 14 18 — 59 1.91 1.91 1.91 2.97 3.80 — 3.5 12.5 14.0 0.8 3.57 4.84 3.50
9 9 12 12 12 — 54 2.08 2.08 2.78 2.78 2.78 — 3.5 12.5 14.0 0.8 3.60 4.84 3.47
9 9 12 12 14 — 56 2.01 2.01 2.68 2.68 3.12 — 3.5 12.5 14.0 0.8 3.59 4.84 3.48
9 9 12 12 18 — 60 1.88 1.88 2.50 2.50 3.74 — 3.5 12.5 14.0 0.8 3.56 4.84 3.51
9 9 12 14 14 — 58 1.94 1.94 2.58 3.02 3.02 — 3.5 12.5 14.0 0.8 3.57 4.84 3.50
9 9 12 14 18 — 62 1.81 1.81 2.42 2.82 3.64 — 3.5 12.5 14.0 0.8 3.55 4.84 3.52
9 9 14 14 14 — 60 1.87 1.87 2.92 2.92 2.92 — 3.5 12.5 14.0 0.8 3.56 4.84 3.51
9 12 12 12 12 — 57 1.98 2.63 2.63 2.63 2.63 — 3.5 12.5 14.0 0.8 3.58 4.84 3.49
9 12 12 12 14 — 59 1.91 2.54 2.54 2.54 2.97 — 3.5 12.5 14.0 0.8 3.57 4.84 3.50
9 12 12 14 14 — 61 1.84 2.46 2.46 2.87 2.87 — 3.5 12.5 14.0 0.8 3.56 4.84 3.51
12 12 12 12 12 — 60 2.50 2.50 2.50 2.50 2.50 — 3.5 12.5 14.0 0.8 3.56 4.84 3.51
12 12 12 12 14 — 62 2.42 2.42 2.42 2.42 2.82 — 3.5 12.5 14.0 0.8 3.55 4.84 3.52
7 7 7 7 7 7 42 2.00 2.00 2.00 2.00 2.00 2.00 3.5 12.0 13.4 0.8 3.32 4.46 3.61
7 7 7 7 7 9 44 2.00 2.00 2.00 2.00 2.00 2.50 3.5 12.5 14.0 0.8 3.57 4.84 3.50
7 7 7 7 7 12 47 1.86 1.86 1.86 1.86 1.86 3.20 3.5 12.5 14.0 0.8 3.55 4.84 3.52
7 7 7 7 7 14 49 1.79 1.79 1.79 1.79 1.79 3.55 3.5 12.5 14.0 0.8 3.54 4.84 3.53
7 7 7 7 7 18 53 1.65 1.65 1.65 1.65 1.65 4.25 3.5 12.5 14.0 0.8 3.51 4.84 3.56
7 7 7 7 7 24 59 1.48 1.48 1.48 1.48 1.48 5.10 3.5 12.5 14.0 0.8 3.48 4.84 3.59
7 7 7 7 9 9 46 1.90 1.90 1.90 1.90 2.45 2.45 3.5 12.5 14.0 0.8 3.56 4.84 3.51
7 7 7 7 9 12 49 1.79 1.79 1.79 1.79 2.29 3.05 3.5 12.5 14.0 0.8 3.54 4.84 3.53
7 7 7 7 9 14 51 1.72 1.72 1.72 1.72 2.20 3.42 3.5 12.5 14.0 0.8 3.53 4.84 3.54
7 7 7 7 9 18 55 1.59 1.59 1.59 1.59 2.05 4.09 3.5 12.5 14.0 0.8 3.50 4.84 3.57
7 7 7 7 9 24 61 1.43 1.43 1.43 1.43 1.85 4.93 3.5 12.5 14.0 0.8 3.47 4.84 3.60
7 7 7 7 12 12 52 1.68 1.68 1.68 1.68 2.89 2.89 3.5 12.5 14.0 0.8 3.52 4.84 3.55
7 7 7 7 12 14 54 1.62 1.62 1.62 1.62 2.78 3.24 3.5 12.5 14.0 0.8 3.51 4.84 3.56
7 7 7 7 12 18 58 1.51 1.51 1.51 1.51 2.59 3.87 3.5 12.5 14.0 0.8 3.48 4.84 3.59
7 7 7 7 14 14 56 1.56 1.56 1.56 1.56 3.13 3.13 3.5 12.5 14.0 0.8 3.50 4.84 3.57
7 7 7 7 14 18 60 1.46 1.46 1.46 1.46 2.92 3.74 3.5 12.5 14.0 0.8 3.47 4.84 3.60
7 7 7 9 9 9 48 1.82 1.82 1.82 2.34 2.34 2.34 3.5 12.5 14.0 0.8 3.55 4.84 3.52
7 7 7 9 9 12 51 1.72 1.72 1.72 2.21 2.21 2.92 3.5 12.5 14.0 0.8 3.53 4.84 3.54
7 7 7 9 9 14 53 1.65 1.65 1.65 2.12 2.12 3.31 3.5 12.5 14.0 0.8 3.51 4.84 3.56
7 7 7 9 9 18 57 1.54 1.54 1.54 1.97 1.97 3.94 3.5 12.5 14.0 0.8 3.49 4.84 3.58
7 7 7 9 12 12 54 1.62 1.62 1.62 2.08 2.78 2.78 3.5 12.5 14.0 0.8 3.51 4.84 3.56
7 7 7 9 12 14 56 1.56 1.56 1.56 2.01 2.68 3.13 3.5 12.5 14.0 0.8 3.50 4.84 3.57
7 7 7 9 12 18 60 1.46 1.46 1.46 1.88 2.50 3.74 3.5 12.5 14.0 0.8 3.47 4.84 3.60
7 7 7 9 14 14 58 1.51 1.51 1.51 1.93 3.02 3.02 3.5 12.5 14.0 0.8 3.48 4.84 3.59
7 7 7 12 12 12 57 1.54 1.54 1.54 2.63 2.63 2.63 3.5 12.5 14.0 0.8 3.49 4.84 3.58
7 7 7 12 12 14 59 1.48 1.48 1.48 2.54 2.54 2.98 3.5 12.5 14.0 0.8 3.48 4.84 3.59
7 7 7 12 14 14 61 1.43 1.43 1.43 2.47 2.87 2.87 3.5 12.5 14.0 0.8 3.47 4.84 3.60
7 7 9 9 9 9 50 1.75 1.75 2.25 2.25 2.25 2.25 3.5 12.5 14.0 0.8 3.53 4.84 3.54
7 7 9 9 9 12 53 1.65 1.65 2.12 2.12 2.12 2.84 3.5 12.5 14.0 0.8 3.51 4.84 3.56
7 7 9 9 9 14 55 1.59 1.59 2.05 2.05 2.05 3.17 3.5 12.5 14.0 0.8 3.50 4.84 3.57
7 7 9 9 9 18 59 1.48 1.48 1.91 1.91 1.91 3.81 3.5 12.5 14.0 0.8 3.48 4.84 3.59
7 7 9 9 12 12 56 1.56 1.56 2.01 2.01 2.68 2.68 3.5 12.5 14.0 0.8 3.50 4.84 3.57
7 7 9 9 12 14 58 1.51 1.51 1.94 1.94 2.59 3.01 3.5 12.5 14.0 0.8 3.48 4.84 3.59
7 7 9 9 12 18 62 1.41 1.41 1.81 1.81 2.42 3.64 3.5 12.5 14.0 0.8 3.46 4.84 3.61
7 7 9 9 14 14 60 1.46 1.46 1.88 1.88 2.91 2.91 3.5 12.5 14.0 0.8 3.47 4.84 3.60
7 7 9 12 12 12 59 1.48 1.48 1.92 2.54 2.54 2.54 3.5 12.5 14.0 0.8 3.48 4.84 3.59
7 7 9 12 12 14 61 1.43 1.43 1.85 2.46 2.46 2.87 3.5 12.5 14.0 0.8 3.47 4.84 3.60
7 7 12 12 12 12 62 1.41 1.41 2.42 2.42 2.42 2.42 3.5 12.5 14.0 0.8 3.46 4.84 3.61
7 9 9 9 9 9 52 1.70 2.16 2.16 2.16 2.16 2.16 3.5 12.5 14.0 0.8 3.52 4.84 3.55
- 355 -
OUTDOOR UNIT AOYG45LBLA6

Fujitsu AOYG36LBLA5 Specifications

General

Type	Air conditioner outdoor unit
Multi-split	No
Product color	White
Compressor type	Rotary
Gas hose diameter	9.52 mm
Hose length (max)	80 m
Hose length (min)	25 m
Inverter technology	-
Liquid hose diameter	6.35 mm
Refrigerating medium	R410A
Air conditioner functions	Cooling, Heating
Cooling capacity in watts (max)	12500 W
Heating capacity in watts (max)	14000 W
Heating capacity in watts (min)	3500 W
Cooling capacity in watts (nominal)	- W
Operating temperature (cooling) (T-T)	-10 - 46 °C
Operating temperature (heating) (T-T)	-15 - 24 °C
AC input voltage	230 V
AC input frequency	50 Hz
Design load (cooling)	- kW
Hourly energy consumption (cooling)	- kWh
Indoor unit noise level (high speed)	- dB
Outdoor unit depth	370 mm
Outdoor unit width	970 mm
Outdoor unit height	998 mm
Outdoor unit weight	94000 g
Outdoor units quantity	1
Outdoor unit noise level	67 dB
Outdoor unit sound power level	68 dB
