Fujitsu AOYG36LBLA5 User Manual

Indoor unit connecting
capacity
Outdoor temperature
Indoor temperature
16.0 °CDB 18.0 °CDB 20.0 °CDB 22.0 °CDB 24.0 °CDB
kBtu/h °CDB °CWB TC IP TC IP TC IP TC IP TC IP
45
-15.0
-16.0 10.83 5.10 10.31 5.10 9.90 5.10 9.69 5.09 9.49 5.08
-10.0 -11.0 12.04 5.10 11.48 5.10 11.10 5.10 10.86 5.09 10.63 5.08
-5.0 -7.0 13.43 5.10 12.87 5.10 12.40 5.10 12.21 5.09 12.03 5.07
0.0 -2.0 15.48 5.10 14.89 5.10 14.30 5.10 13.95 5.07 13.61 5.05
5.0 3.0 17.68 5.10 16.85 5.10 15.60 5.10 15.08 4.95 14.56 4.80
7.0 6.0 18.50 4.77 17.40 4.68 16.00 4.59 15.25 4.36 14.50 4.12
10.0 8.0 18.37 4.77 17.28 4.68 16.00 4.59 15.26 4.46 14.52 4.33
15.0 10.0 18.34 4.49 17.17 4.40 16.00 4.28 15.32 4.15 14.63 4.02
20.0 15.0 17.37 3.89 16.28 3.81 15.27 3.70 14.68 3.58 14.08 3.47
24.0 18.0 16.35 3.55 15.41 3.48 14.55 3.38 14.30 3.35 14.04 3.31
44
-15.0
-16.0 10.83 5.10 10.31 5.10 9.90 5.10 9.69 5.09 9.49 5.08
-10.0 -11.0 12.04 5.10 11.48 5.10 11.10 5.10 10.86 5.09 10.63 5.08
-5.0 -7.0 13.43 5.10 12.87 5.10 12.40 5.10 12.21 5.09 12.03 5.07
0.0 -2.0 15.48 5.10 14.89 5.10 14.30 5.10 13.95 5.07 13.61 5.05
5.0 3.0 17.68 5.10 16.85 5.10 15.60 5.10 15.08 4.95 14.56 4.80
7.0 6.0 18.50 4.77 17.40 4.68 16.00 4.59 15.25 4.36 14.50 4.12
10.0 8.0 18.37 4.77 17.28 4.68 16.00 4.59 15.26 4.46 14.52 4.33
15.0 10.0 18.34 4.49 17.17 4.40 16.00 4.28 15.32 4.15 14.63 4.02
20.0 15.0 17.37 3.89 16.28 3.81 15.27 3.70 14.68 3.58 14.08 3.47
24.0 18.0 16.35 3.55 15.41 3.48 14.55 3.38 14.30 3.35 14.04 3.31
43
-15.0
-16.0 10.58 4.98 10.08 4.98 9.68 4.98 9.47 4.97 9.27 4.96
-10.0 -11.0 11.77 4.98 11.22 4.98 10.85 4.98 10.62 4.97 10.39 4.96
-5.0 -7.0 13.12 4.98 12.57 4.98 12.12 4.98 11.94 4.97 11.75 4.95
0.0 -2.0 15.13 4.98 14.55 4.98 13.98 4.98 13.64 4.95 13.30 4.93
5.0 3.0 17.28 4.98 16.47 4.98 15.25 4.98 14.74 4.83 14.23 4.68
7.0 6.0 18.08 4.66 17.00 4.57 15.64 4.48 14.90 4.25 14.17 4.02
10.0 8.0 17.95 4.66 16.89 4.57 15.64 4.48 14.91 4.36 14.19 4.23
15.0 10.0 17.92 4.39 16.78 4.30 15.64 4.18 14.97 4.05 14.30 3.92
20.0 15.0 16.98 3.80 15.91 3.72 14.92 3.62 14.34 3.50 13.76 3.38
24.0 18.0 15.98 3.47 15.06 3.40 14.22 3.30 13.97 3.27 13.72 3.24
42
-15.0
-16.0 10.34 4.86 9.84 4.86 9.45 4.86 9.25 4.85 9.06 4.84
-10.0 -11.0 11.49 4.86 10.95 4.86 10.60 4.86 10.37 4.85 10.15 4.84
-5.0 -7.0 12.82 4.86 12.28 4.86 11.84 4.86 11.66 4.85 11.48 4.83
0.0 -2.0 14.78 4.86 14.21 4.86 13.65 4.86 13.32 4.83 12.99 4.81
5.0 3.0 16.88 4.86 16.08 4.86 14.89 4.86 14.40 4.72 13.90 4.57
7.0 6.0 17.66 4.55 16.61 4.46 15.27 4.37 14.56 4.15 13.84 3.93
10.0 8.0 17.54 4.55 16.50 4.46 15.27 4.37 14.57 4.25 13.86 4.13
15.0 10.0 17.51 4.28 16.39 4.20 15.27 4.07 14.62 3.95 13.97 3.83
20.0 15.0 16.58 3.71 15.54 3.63 14.58 3.53 14.01 3.41 13.44 3.30
24.0 18.0 15.61 3.38 14.71 3.32 13.89 3.22 13.65 3.19 13.40 3.16
41
-15.0
-16.0 10.09 4.74 9.61 4.74 9.23 4.74 9.03 4.73 8.84 4.72
-10.0 -11.0 11.22 4.74 10.69 4.74 10.34 4.74 10.12 4.73 9.90 4.72
-5.0 -7.0 12.51 4.74 11.99 4.74 11.55 4.74 11.38 4.73 11.21 4.72
0.0 -2.0 14.43 4.74 13.88 4.74 13.33 4.74 13.00 4.72 12.68 4.69
5.0 3.0 16.48 4.74 15.70 4.74 14.54 4.74 14.05 4.60 13.57 4.46
7.0 6.0 17.24 4.44 16.21 4.35 14.91 4.27 14.21 4.05 13.51 3.83
10.0 8.0 17.12 4.44 16.11 4.35 14.91 4.27 14.22 4.15 13.53 4.03
15.0 10.0 17.09 4.17 16.00 4.09 14.91 3.97 14.27 3.85 13.64 3.73
20.0 15.0 16.19 3.61 15.17 3.54 14.23 3.44 13.67 3.33 13.12 3.22
24.0 18.0 15.24 3.30 14.36 3.24 13.56 3.14 13.32 3.11 13.08 3.08
40
-15.0
-16.0 9.84 4.62 9.38 4.62 9.00 4.62 8.81 4.61 8.63 4.60
-10.0 -11.0 10.95 4.62 10.43 4.62 10.09 4.62 9.88 4.61 9.66 4.60
-5.0 -7.0 12.21 4.62 11.70 4.62 11.27 4.62 11.10 4.61 10.93 4.60
0.0 -2.0 14.08 4.62 13.54 4.62 13.00 4.62 12.69 4.60 12.37 4.57
5.0 3.0 16.08 4.62 15.32 4.62 14.18 4.62 13.71 4.48 13.24 4.35
7.0 6.0 16.82 4.32 15.82 4.24 14.55 4.16 13.86 3.94 13.18 3.73
10.0 8.0 16.70 4.32 15.71 4.24 14.55 4.16 13.87 4.04 13.20 3.92
15.0 10.0 16.67 4.07 15.61 3.99 14.55 3.87 13.92 3.75 13.30 3.64
20.0 15.0 15.79 3.52 14.80 3.45 13.88 3.35 13.34 3.25 12.80 3.14
24.0 18.0 14.87 3.21 14.01 3.15 13.23 3.06 13.00 3.03 12.76 3.00
39
-15.0
-16.0 9.60 4.50 9.14 4.50 8.78 4.50 8.59 4.49 8.41 4.48
-10.0 -11.0 10.67 4.50 10.17 4.50 9.84 4.50 9.63 4.49 9.42 4.48
-5.0 -7.0 11.90 4.50 11.40 4.50 10.99 4.50 10.83 4.49 10.66 4.48
0.0 -2.0 13.72 4.50 13.20 4.50 12.68 4.50 12.37 4.48 12.06 4.45
5.0 3.0 15.67 4.50 14.94 4.50 13.83 4.50 13.37 4.37 12.91 4.23
7.0 6.0 16.40 4.21 15.42 4.13 14.18 4.05 13.52 3.84 12.85 3.63
10.0 8.0 16.28 4.21 15.32 4.13 14.18 4.05 13.53 3.93 12.87 3.82
15.0 10.0 16.26 3.96 15.22 3.88 14.18 3.77 13.58 3.66 12.97 3.54
20.0 15.0 15.40 3.43 14.43 3.36 13.53 3.27 13.01 3.16 12.48 3.06
24.0 18.0 14.49 3.13 13.66 3.07 12.90 2.98 12.67 2.95 12.45 2.92
38
-15.0
-16.0 9.35 4.37 8.91 4.37 8.55 4.37 8.37 4.37 8.19 4.36
-10.0 -11.0 10.40 4.37 9.91 4.37 9.59 4.37 9.38 4.37 9.18 4.36
-5.0 -7.0 11.59 4.37 11.11 4.37 10.71 4.37 10.55 4.36 10.39 4.35
0.0 -2.0 13.37 4.37 12.86 4.37 12.35 4.37 12.05 4.35 11.75 4.33
5.0 3.0 15.27 4.37 14.55 4.37 13.48 4.37 13.03 4.24 12.58 4.12
7.0 6.0 15.98 4.10 15.03 4.02 13.82 3.94 13.17 3.74 12.52 3.54
10.0 8.0 15.87 4.10 14.93 4.02 13.82 3.94 13.18 3.83 12.54 3.72
15.0 10.0 15.84 3.85 14.83 3.78 13.82 3.67 13.23 3.56 12.64 3.45
20.0 15.0 15.00 3.34 14.06 3.27 13.19 3.18 12.67 3.08 12.16 2.97
24.0 18.0 14.12 3.05 13.31 2.99 12.57 2.90 12.35 2.87 12.13 2.84
37
-15.0
-16.0 9.11 4.26 8.67 4.26 8.33 4.26 8.15 4.25 7.98 4.24
-10.0 -11.0 10.13 4.26 9.65 4.26 9.33 4.26 9.14 4.25 8.94 4.24
-5.0 -7.0 11.29 4.26 10.82 4.26 10.43 4.26 10.27 4.25 10.11 4.24
0.0 -2.0 13.02 4.26 12.52 4.26 12.03 4.26 11.73 4.24 11.44 4.22
5.0 3.0 14.87 4.26 14.17 4.26 13.12 4.26 12.68 4.13 12.25 4.01
7.0 6.0 15.56 3.98 14.63 3.91 13.45 3.83 12.82 3.63 12.19 3.44
10.0 8.0 15.45 3.98 14.53 3.91 13.45 3.83 12.83 3.72 12.21 3.62
15.0 10.0 15.42 3.75 14.44 3.68 13.45 3.57 12.88 3.46 12.31 3.35
20.0 15.0 14.61 3.25 13.69 3.18 12.84 3.09 12.34 2.99 11.84 2.89
24.0 18.0 13.75 2.96 12.96 2.91 12.24 2.82 12.02 2.79 11.81 2.77
DESIGN & TECHNICAL MANUAL
- 378 -
OUTDOOR UNIT AOYG45LBLA6

Fujitsu AOYG36LBLA5 Specifications

General

Type	Air conditioner outdoor unit
Multi-split	No
Product color	White
Compressor type	Rotary
Gas hose diameter	9.52 mm
Hose length (max)	80 m
Hose length (min)	25 m
Inverter technology	-
Liquid hose diameter	6.35 mm
Refrigerating medium	R410A
Air conditioner functions	Cooling, Heating
Cooling capacity in watts (max)	12500 W
Heating capacity in watts (max)	14000 W
Heating capacity in watts (min)	3500 W
Cooling capacity in watts (nominal)	- W
Operating temperature (cooling) (T-T)	-10 - 46 °C
Operating temperature (heating) (T-T)	-15 - 24 °C
AC input voltage	230 V
AC input frequency	50 Hz
Design load (cooling)	- kW
Hourly energy consumption (cooling)	- kWh
Indoor unit noise level (high speed)	- dB
Outdoor unit depth	370 mm
Outdoor unit width	970 mm
Outdoor unit height	998 mm
Outdoor unit weight	94000 g
Outdoor units quantity	1
Outdoor unit noise level	67 dB
Outdoor unit sound power level	68 dB
