Mini duct type
MODEL: ARYG07LSLAP
Outdoor temperature
Indoor temperature (°CDB)
16.0 18.0 20.0 22.0 24.0
(°CDB) (°CWB) TC TC TC TC TC
-15.0 -16.0 1.73 1.65 1.58 1.55 1.52
-10.0 -11.0 1.93 1.84 1.78 1.74 1.70
-5.0 -7.0 2.15 2.06 1.98 1.95 1.92
0.0 -2.0 2.48 2.38 2.29 2.23 2.18
5.0 3.0 2.83 2.70 2.50 2.41 2.33
7.0 6.0 2.96 2.78 2.56 2.44 2.32
10.0 8.0 2.94 2.77 2.56 2.44 2.32
15.0 10.0 2.93 2.75 2.56 2.45 2.34
20.0 15.0 2.78 2.60 2.44 2.35 2.25
24.0 18.0 2.62 2.47 2.33 2.29 2.25
MODEL: ARYG09LSLAP
Outdoor temperature
Indoor temperature (°CDB)
16.0 18.0 20.0 22.0 24.0
(°CDB) (°CWB) TC TC TC TC TC
-15.0 -16.0 2.23 2.13 2.04 2.00 1.96
-10.0 -11.0 2.48 2.37 2.29 2.24 2.19
-5.0 -7.0 2.77 2.65 2.56 2.52 2.48
0.0 -2.0 3.19 3.07 2.95 2.88 2.81
5.0 3.0 3.65 3.48 3.22 3.11 3.00
7.0 6.0 3.82 3.59 3.30 3.15 2.99
10.0 8.0 3.79 3.56 3.30 3.15 2.99
15.0 10.0 3.78 3.54 3.30 3.16 3.02
20.0 15.0 3.58 3.36 3.15 3.03 2.90
24.0 18.0 3.37 3.18 3.00 2.95 2.90
MODEL: ARYG12LSLAP
Outdoor temperature
Indoor temperature (°CDB)
16.0 18.0 20.0 22.0 24.0
(°CDB) (°CWB) TC TC TC TC TC
-15.0 -16.0 2.97 2.83 2.72 2.66 2.60
-10.0 -11.0 3.30 3.15 3.05 2.98 2.92
-5.0 -7.0 3.68 3.53 3.40 3.35 3.30
0.0 -2.0 4.25 4.09 3.92 3.83 3.73
5.0 3.0 4.85 4.62 4.28 4.14 4.00
7.0 6.0 5.08 4.77 4.39 4.18 3.98
10.0 8.0 5.04 4.74 4.39 4.19 3.98
15.0 10.0 5.03 4.71 4.39 4.20 4.02
20.0 15.0 4.77 4.47 4.19 4.03 3.86
24.0 18.0 4.49 4.23 3.99 3.92 3.85
MODEL: ARYG14LSLAP
Outdoor temperature
Indoor temperature (°CDB)
16.0 18.0 20.0 22.0 24.0
(°CDB) (°CWB) TC TC TC TC TC
-15.0 -16.0 3.46 3.29 3.16 3.10 3.03
-10.0 -11.0 3.85 3.67 3.55 3.47 3.39
-5.0 -7.0 4.29 4.11 3.96 3.90 3.84
0.0 -2.0 4.95 4.76 4.57 4.46 4.35
5.0 3.0 5.65 5.38 4.98 4.82 4.65
7.0 6.0 5.91 5.56 5.11 4.87 4.63
10.0 8.0 5.87 5.52 5.11 4.87 4.64
15.0 10.0 5.86 5.48 5.11 4.89 4.67
20.0 15.0 5.55 5.20 4.88 4.69 4.50
24.0 18.0 5.22 4.92 4.65 4.57 4.48
MODEL: ARYG18LSLAP
Outdoor temperature
Indoor temperature (°CDB)
16.0 18.0 20.0 22.0 24.0
(°CDB) (°CWB) TC TC TC TC TC
-15.0 -16.0 4.45 4.23 4.07 3.98 3.90
-10.0 -11.0 4.94 4.71 4.56 4.46 4.36
-5.0 -7.0 5.51 5.28 5.09 5.02 4.94
0.0 -2.0 6.36 6.11 5.87 5.73 5.59
5.0 3.0 7.26 6.92 6.41 6.19 5.98
7.0 6.0 7.60 7.14 6.57 6.26 5.95
10.0 8.0 7.54 7.10 6.57 6.27 5.96
15.0 10.0 7.53 7.05 6.57 6.29 6.01
20.0 15.0 7.13 6.68 6.27 6.03 5.78
24.0 18.0 6.71 6.33 5.98 5.87 5.77
DESIGN & TECHNICAL MANUAL
- 382 -
OUTDOOR UNIT AOYG45LBLA6
