Installation space requirement

Provide sufficient installation space for product safety.

Unit: mm

45 or more

1,800 or more

63 or more

Outline of unit

25 or more

52 or more

144 or more

1,500 or more

86 or more

- 33 -

MULTI TYPE

5, 6 ROOMS TYPE
