Fujitsu AOYG36LBLA5 - Page 92

¢
Models: ASYG24LFCA and ASYG24LFCC
Measuring conditions
Fan speed Operation mode
HIGH FAN
Top view
Vertical airflow direction louver: Up
Horizontal airflow direction louver: Center
2.0
1.0
0.5
0
1
1
2
2
(m)
012345678
Unit: m/s
Top view
Vertical airflow direction louver: Up
Horizontal airflow direction louver: Left & Right
2.0
2.0
1.0
1.0
0.5
0.5
Unit: m/s
(m)
012345678
(m)
0
1
1
2
2
3
3
Side view
Vertical airflow direction louver: Up
Horizontal airflow direction louver: Center
2.0
1.0
0.5
Unit: m/s
(m)
012345678
(m)
0
1
2
3
Side view
Vertical airflow direction louver: Down
Horizontal airflow direction louver: Center
2.0
1.0
0.5
Unit: m/s
(m)
012345678
(m)
0
1
2
3
