Fujitsu AOYG45LAT8 User Manual

APPLICABLE MODEL：ALL MODEL
SIDE VIEW
WIRE j
(2 WIRES 1 CONNECTOR)
⑧
WIRE h-1(2 WIRES) (For AOU48RLXFZ)
WIRE h-2 (For AO*G45LAT8,
ROG45LAT8,HOG45LAT8)
25
24
⑨
27
26
28
23
BIND (large size)
WIRE h-1(2 WIRES) (For AOU48RLXFZ)
WIRE h-2 (For AO*G45LAT8,
ROG45LAT8,HOG45LAT8)
BIND (middle size)
WIRE h-1(2 WIRES) (For AOU48RLXFZ)
WIRE h-2 (For AO*G45LAT8,
ROG45LAT8,HOG45LAT8)
Color:BROWN
Color:BLUE
BIND (small size)
WIRE i
SIDE VIEW
Color:GRAY
WIRE i
(2 WIRES 1 CONNECTOR)
BIND (middle size)
WIRE j with insulation
BIND (middle size)
WIRE i with insulation
BIND (small size)
WIRE i
Color:YELLOW
※We have removed theRight panelwhen taking the pictures.
03-16
